System Board Removal/Replacement
Removing and Replacing the System Board

Installing the New System Board

1. Position the system board tray in the new chassis. When it is flat in
the workstation, align the system board tray's keyholes with the
standoffs on the center wall of the chassis, and then slide the system
board tray toward the back of the workstation to seat the standoffs
into their corresponding keyholes.
2. Replace the two T-15 Torx screws that secure the system board tray to
the rear wall of the workstation.
3. Place the old system board try into the protective packaging from the
new replacement system board and put it aside.
22 Chapter 2
