Removing and Replacing the System Board

To avoid system damage, make sure your static-grounding strap is

securely attached to your wrist and to the bare metal on the workstation.

1. Ensure all workstation cables are out of the way to avoid interference

Figure 2-8

Removing the System Board

T-15

Torx

Screws

2. Remove the two T-15 Torx screws at the back of the workstation that

3. Grasp the system-board tray handle and slide the system board tray

Chapter 2

or damage when you remove the system board tray.

secure the system board tray to the rear wall of the workstation.

toward the front of the workstation to unseat the keyhole standoffs.

Using the handle, lift the system board tray out of the workstation

and place it on the conductive sheeting.

System Board Removal/Replacement

Removing and Replacing the System Board

System Board Handle

boar

tray
