6
Preparing for component
installation
To facilitate the installation of components, several steps can be taken to prepare the workstation. This
section describes how to prepare your workstation for component installation.

Disassembly and installation preparation

Use the following table to determine the order of workstation disassembly required before installing
components. (Your workstation components may be different than those listed.)
Table 6-1
To install...
Memory
Expansion card (PCI/
PCIe)
Hard drive
Optical drive
See the workstation Maintenance and Service Guide for chassis lock locations and operation instructions.
*
Preparing the workstation for component
installation
To prepare the workstation:
NOTE:
The workstation contains green plastic touch points at locations where you must manipulate a
button or lever. Green touch points on some components indicate tool-less removal of those
components.
1.
Disconnect power from the system.
2.
Unlock the side access panel or remove any chassis locks.
3.
Remove the side access panel as shown in the following illustrations.
34
Chapter 6 Preparing for component installation
Workstation component installation
Remove...
Chassis locks
*
Chassis locks
Chassis locks
Chassis locks
Then remove...
Then...
Side access panel
Side access panel
Side access panel
Rotate front drive cage
to upward position
(Z210 SFF)
Side access panel
Remove front bezel
Then...
Rotate power supply
to upright position
(Z210 SFF)
ENWW
