Preparing Your Workstation

Before starting the upgrade, use the following procedure to prepare the
workstation:
1 The workstation must be running HP-UX 10.20 or later with Additional Core En-
hancements (ACE) to accommodate the C240 upgrade. If the workstation is run-
ning an older version of HP-UX, update the operating system software before
continuing. Run swlist as super user to view what software products are loaded
in your system. If the product list includes B6193AA, you do not need to update
HP-UX.
2 Determine the workstation's LAN ID by entering the following command:
/usr/sbin/lanscan
The output is similar to the following:
Hardware Station
Path Address
2.0.2 0x08000970ECC0 0
Record the LAN ID here. You will need it after installing the new system
board:
Enter LAN ID: ___ ___ ___ ___ ___ ___ -___ ___ ___ ___ ___ ___
You must supply the dash (-) between the first six digits and the last six digits.
Using the above output example, the LAN ID is 080009-70ECC0.
After you install the new CPU board or I/O board and power on the system for
the first time, you will be prompted for the LAN ID.
3 Log out of your system and enter a command line session as follows:
HP VUE: At the login window, select Options, then select No Windows.
HP CDE: At the login window, select Option, then select
Command Line Login.
4 Power off your workstation by pressing the power button on the front panel.
When you press the power button, the workstation automatically shuts down the
operating system before it powers off the system.
Dev Hardware Net-Interface
lu State NameUnit State ID
UP lan0 UP
Preparing Your Workstation
NM Encapsulation Mjr
Methods Num
4 ETHER 52
