Figure 4-11 Grounding Point on Rear of
To guarantee the security of the person and the device, the RG-S7800C must be well-grounded. The grounding resistance shall
be less than 1Ω.
A service person shall check whether or not the socket-outlet from which the equipment is to be powered provides a connection
the building protective earth. If not, the service person shall arrange for the installation of a protective earthing conductor from the
separate protective earthing terminal to the protective earth wire in the building.
The socket-outlet shall be installed near the equipment and shall be easily.
When installing the unit, always make the ground connection first and disconnect it last.
The cross-sectional area of protective earthing conductor shall be at least 2.5 mm

4.8 Installing Power Supplies

The RG-S7808C series switches provide AC power supplies including RG-PA1600I-F and RG-PA600I-F, and PoE power supplies
including RG-PA3000I-PLand RG-PA1600I-PL. The RG-S7805C series switches provide AC power supplies including
and RG-PA460I-F. Before performing the following procedures, wear an anti-static wrist trap close to your kin and keep it grounded.
The RG-S7808C power system provides
configure1+1 power supply redundancy.
RG-S7805C
four power supply slots and two PoE power slots. It is recommended that you
2
(12AWG).
