4.2 Keypad display

The keypad of Goodrive30 series VFD displays the stopped-state parameters, running-state
parameters, function parameter editing status, and fault alarm status.

4.2.1 Displaying stopped-state parameters

When the VFD is in stopped state, the keypad displays stopped-state parameters, as shown in
Figure 4-3.
In the stopped state, parameters in various states can be displayed. You can determine which
parameters are displayed by setting the binary bits of P07.07. For definitions of the bits, see
the description of P07.07.
In stopping state, there are 14 parameters that can be selected for display, including set
frequency, bus voltage, input terminal status, output terminal status, PID reference value, PID
feedback value, torque setting, AI1, AI2, AI3, high-speed pulse HDI frequency, PLC and the
current step of multi-step speed, pulse counting value, length value. P07.07 can select the
parameter to be displayed or not by bit, and you can press 》/SHIFT to shift selected
parameters from left to right or press QUICK/JOG to shift selected parameters from right to
left.

4.2.2 Displaying running-state parameters

After receiving a valid running command, the VFD enters the running state, and the keypad
displays running-state parameters, with the RUN/TUNE indicator on. The on/off state of the
FWD/REV indicator is determined by the current running direction. It is shown in Figure 4-3.
In running state, there are 24 parameters that can be selected for display, including running
frequency, set frequency, bus voltage, output voltage, output current, running speed, output
AI1. When the external common keypad (without the function of parameter
copy) is valid, the difference between the local keypad AI1 and the external
keypad AI1 is: When the external keypad AI1 is set to the Min. value, the
local keypad AI1 will be valid and P17.19 will be the voltage of the local
keypad AI1; otherwise, the external keypad AI1 will be valid and P17.19 will
be the voltage of the external keypad AI1.
Note: If the external keypad AI1 is frequency reference source, adjust the
local potentiometer AI1 to 0V/0mA before starting the VFD.
External keypad port. When the external keypad with the function of
parameter copying is valid, the local keypad LED is off. When the external
keypad without the function of parameter copying is valid, the local and
external keypad LEDs are on.
Note: Only the external keypad which has the function of parameters copy
owns the function of parameters copy, other keypads do not have. (only for
the VFDs ≤ 2.2kW)
