INVT Goodrive30 VFD Series Operation Manual page 100

Goodrive30 Series VFD
Function
Name
code
Low
frequency
P09.14
proportional
gain (Kp)
ACC/DEC
P09.15 time of PID
command
PID output
P09.16
filter time
the feedback changes, it needs more time to
offset the impact of continuous working and the
integration will change with the trend.
1: Stop integral control after the frequency
reaches upper/lower limit. If the integration
keeps stable, and the trend between the
reference and the feedback changes, the
integration will change with the trend quickly.
Tens place:
0: The same with the set direction. If the output
of PID control is different from the current
running direction, 0 will be output forcedly.
1: Contrary to the set direction. If the output of
PID control is different from the current running
direction, the closed-loop regulation output
opposite to the current running direction is
executed.
Hundreds place:
0: Limit based on the max. frequency
1: Limit based on A frequency
Thousands place:
0: A+B frequency, ACC/DEC of main reference A
frequency source buffering is invalid
1: A+B frequency, ACC/DEC of main reference A
frequency source buffering is valid, ACC and
DEC are determined by P08.04 (ACC time 4)
0.00–100.00
0.0–1000.0s
0.000–10.000s
Description
-94-
Function parameter list
Default Modify
○
1.00
○
0.0s
○
0.000s
