Goodrive30 Series VFD
Function
Name
code
P17.17 Reserved
Counting
P17.18
value
AI1 input
P17.19
voltage
AI2 input
P17.20
voltage
AI3 input
P17.21
voltage
HDI input
P17.22
frequency
PID
P17.23 reference
value
PID
P17.24 feedback
value
Motor
P17.25 power
factor
Current
P17.26 running
time
Simple PLC
and current
step
P17.27
number
of multi-step
speed
ASR
P17.28 controller
output
Magnetic
P17.29 pole angle
of SM
Displays the current counting number of the
VFD.
Range: 0–65535
Displays input signal of AI1.
Range: 0.00–10.00V
Displays input signal of AI2.
Range: 0.00–10.00V
Displays input signal of AI3.
Range: -10.00–10.00V
Displays input frequency of HDI.
Range: 0.000–50.000kHz
Displays PID reference value.
Range: -100.0–100.0%
Displays PID feedback value.
Range: -100.0–100.0%
Displays the power factor of current motor.
Range: -1.00–1.00
Displays current running time of the VFD.
Range: 0–65535min
Displays simple PLC and current step number of
multi-step speed
Range: 0–15
Displays the speed loop ASR controller output
value under vector control mode, relative to the
percentage of rated torque of the motor.
Range: -300.0%–+300.0% (of the rated motor
current)
Displays the magnetic pole angle of synchronous
motor.
Range: 0.0–360.0
Description
-109-
Function parameter list
Default Modify
●
0
●
0.00V
●
0.00V
●
0.00V
●
0.000kHz
●
0.0%
●
0.0%
●
0.00
●
0min
●
0
●
0.0%
●
0.0
