Goodrive30 Series VFD
Function
Name
code
PLC restart
P10.36
mode
Multi-step
P10.37 time unit
selection
BIT3 BIT2
BIT5 BIT4
BIT7 BIT6
BIT9 BIT8
BIT11 BIT10 13
BIT13 BIT12 14
BIT15 BIT14 15
Select corresponding ACC/DEC time, and then
convert 16-bit binary number into hexadecimal
number, and then set corresponding function
codes.
ACC/DEC time 1 is set by P00.11 and P00.12;
ACC/DEC time 2 is set by P08.00 and P08.01;
ACC/DEC time 3 is set by P08.02 and P08.03;
ACC/DEC time 4 is set by P08.04 and P08.05.
Setting range: 0x0000–0xFFFF
0: Restart from the first step, namely if the VFD
stops during running (caused by stop command,
fault or power down), it will run from the first step
after restart.
1: Continue running from the step frequency
when interruption occurred, namely if the VFD
stops during running (caused by stop command
or fault), it will record the running time of current
step, and enters this step automatically after
restart, then continue running at the frequency
defined by this step in the remaining time.
0: Second; the running time of each step is
counted in seconds;
1: Minute; the running time of each step is
counted in minutes.
Description
9 00 01
10 00 01
11 00 01
12 00 01
00 01
00 01
00 01
-98-
Function parameter list
Default
10 11
10 11
10 11
10 11
10 11
10 11
10 11
0
0
Modify
◎
◎
