P13 group SM control

Function
Name
code
Pull-in
current
P13.00
reduction
coefficient
Initial pole
P13.01 detection
method
Pull-in
P13.02
current 1
Pull-in
P13.03
current 2
Speed
Actual detection
value
Set detection
value
t1<t2, so the VFD continues running
t2=P11.15
Setting range of P11.15: 0.0–10.0s
0: Disable
1: Enable. When the grid voltage drops to the
rated voltage, the VFD ensures the rated output
torque by automatic frequency reduction.
0.0–100.0%
0: Do not detect
1: High-frequency superposition (reserved)
2: Pulse superposition
Pull-in current is the pole positioning current.
Pull-in current 1 is valid within the lower limit of
pull-in current switchover frequency threshold. If
you need to increase the starting torque,
increase the value of the function code properly.
Setting range: 0.0%–100.0% (of the motor rated
current)
Pull-in current is the pole positioning current.
Pull-in current 2 is valid within the upper limit of
pull-in current switchover frequency threshold.
Generally, you do not need to modify the function
Description
t1
t2
Running Fault output
Description
-103-
Function parameter list
Default
Time t
dEu
0
Default
80.0%
0
20.0%
10.0%
