System Configuration - Mitsubishi Electric MELDAS MDS-R Series Specifications And Instruction Manual

1-1 System configuration

From NC
To 24V
power supply
1st axis
servomotor
Downloaded from ManualsNet.com
Servo drive unit
(MDS-R-V1)
Regenerative
resistor unit
Grounding
Contactor
(Note)
Prepared by
user
Circuit
protector
(Note)
Prepared by
user
3-phase 200VAC
power supply
search engine
1. Introduction
Servo drive unit
(MDS-R-V2)
To 24V
power supply
To 3rd axis
servomotor
To 3rd axis
servomotor
2nd axis
servomotor
1 - 2
Battery unit
(MDS-A-BT)
Terminator
(A-TM)
Regenerative
resistor unit
Grounding
Contactor
(Note)
Prepared by
user
Circuit
protector
(Note)
Prepared by
user
3-phase 200VAC
power supply
