・HF123S-A48
・HF123BS-A48
Downloaded from ManualsNet.com
38.2
13
Detector connector
CM10-R10P
Power connector
CE05-2A18-10PD
43.5
13
Detector connector
59
CM10-R10P
Brake connector
CM10-R2P
Power connector
CE05-2A18-10PD
search engine
2. Specifications
140.5
55
3
12
50
Oil seal
20.9
79.8
55
175
12
3
50
Oil seal
20.9
79.8
2 - 33
[Unit:mm]
4- 9 mounting hole
Use a hexagon
socket bolt.
130 SQ.
13.5
58
4- 9 mounting hole
Use a hexagon
socket bolt.
130 SQ.
13.5
29
58
