(3) Disturbance observer
The disturbance observer can reduce the effect caused by disturbance, frictional resistance or
torsion vibration during cutting by estimating the disturbance torque and compensating it. It also is
effective in suppressing the vibration caused by speed leading compensation control.
<Setting method>
<1> Adjust VGN1 to the value where vibration does not occur, and then lower it 10 to 20%.
<2> Set the load inertia scale (SV037 (JL)) with a percentage in respect to the motor inertia of the
<3> Set the observer filter band (observer pole) in the disturbance observer 1 (SV043 (OBS1)), and
<4> Set the observer gain in disturbance observer 2 (SV044 (OBS2)). The disturbance observer
<Measuring the load inertia>
If the load inertia is not clear, it can be estimated with the following method.
<1> Set the torque offset (SV032 (TOF)) for the unbalance axis. (Refer to "9-3-4 (2) Unbalance
<2> Set JL = 100, OBS1 = 600 and OBS2 =0, and reciprocate the axis within the range that it can
<3> Measure the estimated disturbance torque with the D/A output, and raise JL until the
Speed
command
Estimated
disturbance
No. Abbrev.
SV037 JL
SV043 OBS1
SV044 OBS2
Downloaded from ManualsNet.com
total load inertia.
estimate the high frequency disturbance to suppress the vibration. Set "100" as a standard.
will function here for the first time. Set 100 first, and if vibration does not occur, increase the
setting by 50 at a time to increase the observer effect.
torque compensation".)
be moved smoothly. Set the acceleration/deceleration time constant so that the acceleration/
deceleration torque is larger than the stall (rated) torque (100% or more).
disturbance torque during acceleration/deceleration is small (until it cannot be observed). Even
when the torque offset is set and JL is an appropriate value, if the axis has a large friction, the
frictional torque will remain in the estimated disturbance torque. Judge the JL setting value,
with frictional torque remaining, as the machine's load inertia scale as shown below.
0
0
torque
JL: Too small
Parameter name
Load inertia scale Set "the motor inertia + motor axis conversion load inertia" in respect to the
motor inertia.
SV037(JL) =
Disturbance observer Set the disturbance observer filter band.
filter frequency Set to "100" as a standard.
To use the disturbance observer, also set SV037 (JL) and SV044 (OBS2).
When not using, set to "0".
Disturbance observer Set the disturbance observer gain. The standard setting is "100" to "300".
gain To use the disturbance observer, also set SV037 (JL) and SV043 (OBS1).
When not using, set to "0".
1. The estimated disturbance torque can be output to the D/A output even if the
disturbance observer gain is zero (OBS2 = 0), and the disturbance observer
is not functioning.
2. Sections at which the machine is not moving smoothly are estimated as the
POINT
disturbance.
3. The lost motion compensation must be readjusted when the disturbance
observer is started.
search engine
9. Adjustment
0
Frictional torque
0
Time
JL: Appropriate
Explanation
Jl+Jm Jm : Motor inertia
*100
Jm Jl : Motor axis conversion load inertia
9 - 17
0
0
Time
JL: Too large
Setting range
0 to 5000
0 to 1000
0 to 500
Time
(%)
(rad/s)
(%)
