MELSEC iQ-R System Recorder
User's Manual (Startup)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MELSEC iQ-R Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mitsubishi Electric MELSEC iQ-R Series

Summary of Contents for Mitsubishi Electric MELSEC iQ-R Series

  • Page 1 MELSEC iQ-R System Recorder User's Manual (Startup)

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
  • Page 4 [Design Precautions] WARNING  Configure safety circuits external to the programmable controller to ensure that the entire system operates safely even when a fault occurs in the external power supply or the programmable controller. Failure to do so may result in an accident due to an incorrect output or malfunction. (1) Emergency stop circuits, protection circuits, and protective interlock circuits for conflicting operations (such as forward/reverse rotations or upper/lower limit positioning) must be configured external to the programmable controller.
  • Page 5 [Design Precautions] WARNING  Do not write any data to the "system area" and "write-protect area" of the buffer memory in the module. Also, do not use any "use prohibited" signals as an output signal from the CPU module to each module.
  • Page 6 Also, attach an extension connector protective cover to each unused extension cable connector as necessary. Directly touching any conductive parts of the connectors while power is on may result in electric shock. *1 For details, please consult your local Mitsubishi Electric representative.
  • Page 7 [Wiring Precautions] CAUTION  Individually ground the FG and LG terminals of the programmable controller with a ground resistance of 100 ohms or less. Failure to do so may result in electric shock or malfunction.  Use applicable solderless terminals and tighten them within the specified torque range. If any spade solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting in failure.
  • Page 8 [Startup and Maintenance Precautions] WARNING  Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction.  Correctly connect the battery connector. Do not charge, disassemble, heat, short-circuit, solder, or throw the battery into the fire. Also, do not expose it to liquid or strong shock. Doing so will cause the battery to produce heat, explode, ignite, or leak, resulting in injury and fire.
  • Page 9 [Startup and Maintenance Precautions] CAUTION  When connecting an external device with a CPU module or intelligent function module to modify data of a running programmable controller, configure an interlock circuit in the program to ensure that the entire system will always operate safely. For other forms of control (such as program modification, parameter change, forced output, or operating status change) of a running programmable controller, read the relevant manuals carefully and ensure that the operation is safe before proceeding.
  • Page 10 For details on how to eliminate static electricity from the module, refer to the following. Antistatic Precautions Before Using MELSEC iQ-R Series Products (FA-A-0368)  Use a clean and dry cloth to wipe off dirt on the module.

  • Page 11: Conditions Of Use For The Product

    Notwithstanding the above restrictions, Mitsubishi Electric may in its sole discretion, authorize use of the PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi Electric and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required.

  • Page 12: Introduction

    Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the functions and performance of the MELSEC iQ-R series programmable controller to handle the product correctly. When applying the program examples provided in this manual to an actual system, ensure the applicability and confirm that it will not cause system control problems.

  • Page 13: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ..............1 CONDITIONS OF USE FOR THE PRODUCT .
  • Page 14 Ethernet cable ................61 Network camera .

  • Page 15: Relevant Manuals

    System configurations, parameter settings, and operation methods for the online function in GX Works3 [SH-081215ENG] MELSEC iQ-R Module Configuration Manual The combination of the MELSEC iQ-R series modules, common information on the installation/wiring in [SH-081262ENG] the system, and specifications of the power supply module, base unit, SD memory card, and battery...

  • Page 16: Terms

    TERMS Unless otherwise specified, this manual uses the following terms. Term Description Buffer area for data sampling A memory area in a CPU module to pass sampled devices and labels to a recorder module/camera recorder module ONVIF Profile S Simple profiles that focus on functions to deliver and display videos compliant with ONVIF standards ONVIF supported network camera A network camera that supports ONVIF Profile S ...

  • Page 17: Chapter 1 System Recorder

    System Recorder System Recorder is a solution that integrates the following three steps performed in the breakdown maintenance phase. Step Description Supported function Module or tool to be used Recording Labels, servo axes, and camera Recording function Devices and labels •...
  • Page 18 MEMO 1 System Recorder...

  • Page 19: Chapter 2 Performance Specifications

    PERFORMANCE SPECIFICATIONS This chapter shows the performance specifications of System Recorder. Recording Function This section shows the performance specifications of the recording function. Recorder module Item Specification Number of recording settings Up to 4 Maximum number of device and label Maximum number of points that 6 MB (total of all settings) data points that can be sampled/...
  • Page 20 Camera recorder module Item Specification Main Number of recording settings Up to 4  Maximum number of device and label Maximum number of points that 6 MB (total of all settings) data points that can be sampled/ can be sampled accumulated (CPU module) *3*4...

  • Page 21: Chapter 3 Function List

    FUNCTION LIST This chapter shows the function list of System Recorder. For details on the functions, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Recording Function The recording function can be used to output data in a CPU module and video data captured by a network camera to a recording file and save them to a save destination specified in the recording setting when a file saving trigger is satisfied.
  • Page 22 Item Specification Device and label Sampling method • Each scan • Time specification • Trigger instruction (instruction name: DATATRG) • Safety cycle time Time interval • 1 to 60000 ms • 1 to 86400 s • 1 to 1440 m •...
  • Page 23 Item Specification Save folder name Folder name Up to 64 characters Format [Additional information]_[Fixed information] Additional Number of available Up to 54 characters information characters Additional information • Date and time (when a file saving trigger is satisfied or a recording file is saved) •...

  • Page 24: Offline Monitor Function

    Offline Monitor Function The offline monitor function can be used to reproduce the status of a program and operations (videos) of a device when a trouble occurs by using a recording file. Camera Recording Function The camera recording function can be used to record camera videos linked with a CPU module by using Camera Recording Package and a network camera connected to the built-in Ethernet of the CPU module.

  • Page 25: Chapter 4 Procedures For Operation

    PROCEDURES FOR OPERATION Recording Function This section shows the procedures for performing the recording function. Devices and labels only The following shows the procedure for accumulating devices and labels by using a recorder module *1 A camera recorder module can also be used. Mount a CPU module and recorder module on a base unit, and wire them.
  • Page 26 Set parameters of the recorder module. Page 30 Parameter setting In addition, set parameters of the CPU module as necessary. To save a recording file to a file server, the recorder module and the file server must be connected via Ethernet;...
  • Page 27 Make sure that the recording function is running properly. Whether the recording function is running properly can be checked in 'In recording operation' (Un\G1501, Un\G1701, Un\G1901, Un\G2101), the recording monitor, or with the statuses of the LEDs (RUN LED and OPR LED) of the recorder module.
  • Page 28 Video data in addition to devices and labels The following shows the procedure for accumulating devices and labels, and receiving and accumulating video data by using a camera recorder module. Use a dedicated configuration tool for each camera manufacturer to configure the following initial settings for a network camera.
  • Page 29 Set the camera recorder module in the system parameter in GX Works3. System parameters can be set by reading an actual system configuration to a module configuration diagram in GX Works3. After setting the camera recorder module, "Save" is automatically set for "Save Device/Label Operations" in the event history setting in the CPU parameter;...
  • Page 30 Write data such as the parameters and program, and the recording setting to the CPU module at the same time. For details on writing to the CPU module, refer to the following: GX Works3 Operating Manual • The boot operation cannot be performed for a recording setting. To perform it for a program or parameter, the recording setting must be written to the data memory.
  • Page 31 Make sure that the recording function is running properly. If 'Module READY' (X0) and 'Recording function operation status' (X3) are ON, and 'operating' is stored in 'Camera recording status' (Un\G1650 to 1653, Un\G1850 to 1853, Un\G2050 to 2053, Un\G2250 to 2253), the recording function is running properly.

  • Page 32: Parameter Setting

    Parameter setting Parameters of a recorder module/camera recorder module can be set in GX Works3. For details on the parameter setting, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Module parameter Operating procedure Set module parameters of a recorder module/camera recorder module. Recorder module: [Navigation window] ...

  • Page 33: Operating Procedure

    Module extended parameter The following shows the procedure for setting module extended parameters when using a camera recorder module. Operating procedure Open the module extended parameter screen. [Navigation window]  [Parameter]  [Module Information]  [(target module)]  [Module Extended Parameter] Set each item for a network camera in the "Camera Individual Settings"...
  • Page 34 Setting method by acquiring information from a network camera The following shows the method for setting a network camera by actually connecting to the network camera and acquiring information from the connected one. This method can reduce man-hours required to set a network camera. Operating procedure Open the "Camera Individual Settings"...
  • Page 35 When using an ONVIF supported network camera, click the [Camera Access] button in the "Camera Individual Settings" screen. The network camera can be connected by using a web browser. Adjust the settings in the "Camera Individual Settings" screen in the web browser. Click the [Communication Test] button in the "Camera Individual Settings"...
  • Page 36 • A network camera can be searched for when all of the following conditions are satisfied: - A camera recorder module and GX Works3 are online. - The camera recorder module and network camera are connected via Ethernet. - The network camera is started. •...

  • Page 37: Recording Setting

    Recording setting The recording setting for a recorder module/camera recorder module can be configured by using GX Works3. For details on the recording setting, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Operating procedure Display the "Recording Setting" screen. [Navigation window] ...

  • Page 38: Offline Monitor Function

    Offline Monitor Function This section shows the procedures for performing the offline monitor function. Devices and labels only Prepare a recording file. Storage location Operation *1*2*3 SD memory card Select [Recording]  [Read Recording File] in GX Works3 to read a recording file. File server Connect a file server to a personal computer on which the offline monitor function is performed.
  • Page 39 Video data in addition to devices and labels Prepare a recording file. Storage location Operation *1*2*3 SD memory card Select [Recording]  [Read Recording File] in GX Works3 to read a recording file. File server Connect a file server to a personal computer on which the offline monitor function is performed. *1 For details on reading recording files, refer to the following: GX Works3 Operating Manual *2 Project data can also be read at the same time.

  • Page 40: Camera Recording Function

    Camera Recording Function This section shows the procedure for performing the camera recording function. Use FBs included in Camera Recording Package to record a camera video. For details, refer to the following: Camera Recording Package User's Manual Use GX VideoViewer to play the recorded video file. For details, refer to the following: GX VideoViewer Version 1 Operating Manual Data Flow Analysis Function...

  • Page 41: Chapter 5 System Configuration

    SYSTEM CONFIGURATION This chapter shows the system configuration of System Recorder. Overall System Configuration This section shows the overall system configuration of System Recorder. For the system configuration when using the co-recording function, refer to the following: MELSEC iQ-R System Recorder Co-recording Function Reference Manual When using a recorder module and Camera Recording Package Ethernet Type...

  • Page 42: When Using A Camera Recorder Module

    When using a camera recorder module Ethernet Type Engineering tool GX Works3 GX LogViewer GT Designer3 GX VideoViewer PoE switching hub CPU module Camera recorder module Network camera File server *1 Required only when using the GOT offline monitor or the GOT linkage function of a camera recorder module. 5 SYSTEM CONFIGURATION 5.1 Overall System Configuration...

  • Page 43: System Components And Engineering Tools

    System Components and Engineering Tools This section shows the system components and engineering tools for System Recorder. When using the co-recording function, refer to the following: MELSEC iQ-R System Recorder Co-recording Function Reference Manual System components Programmable controllers Module Model name First 3 or 4 digits Firmware Reference...
  • Page 44 Other devices Network camera The following shows the connectable network cameras. • When using Camera Recording Package Refer to the following: Network cameras supporting the Camera recording package (FA-A-0306) Use a MELIPC MI1000 or general-purpose NAS as an external storage. •...

  • Page 45: Engineering Tools

    Engineering tools Engineering tool Model name Version Reference GX Works3 SW1DND-GXW3-E 1.065T or later GX Works3 Operating Manual GX LogViewer Version 1 Operating Manual GX LogViewer SW1DNN-VIEWER-M 1.106K or later GT Designer3 SW1DND-GTWK3-E 1.236W or later GT Designer3 (GOT2000) Screen Design Manual GX VideoViewer Version 1 Operating Manual GX VideoViewer SW1DNN-REPROA-M...

  • Page 46: Configuring Multiple Modules

    Configuring multiple modules The number of network cameras that can be connected to a camera recorder module differs depending on the settings such as the frame rate. Therefore, a system in which multiple camera recorder modules are used must be configured according to the number and settings of required network cameras.
  • Page 47 When setting a camera recorder module as a sub module : Cannot be set Frame rate Resolution VGA (640  480) HD (1280  720) SXVGA (1280  960) FHD (1920  1080) 10/30     Module configuration examples The following tables show recommended module configuration examples for each number and setting of a network camera.

  • Page 48: Recorder Module

    Recorder Module This section explains a recorder module. For details on the functions, module labels, input/output signals, and buffer memory of a recorder module, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Part names The following shows the part names of a recorder module. Name Description RUN LED...
  • Page 49 Name Description SD/RD LED Indicates the data sending/receiving status in Ethernet. • ON: Being sent/received • OFF: Not being sent/received Ethernet port A port for connecting a recorder module to 10BASE-T/100BASE-TX/1000BASE-T. (A recorder module distinguishes among 10BASE-T, 100BASE-TX, and 1000BASE-T depending on an external device.) SD memory card lock switch (SD A switch for disabling access to an SD memory card to remove it.

  • Page 50: Hardware Specifications

    Hardware specifications The following table shows the hardware specifications of a recorder module. Item Specification Ethernet port Interface • 1000BASE-T • 100BASE-TX • 10BASE-T Data transmission speed 1000BASE-T 1 Gbps 100BASE-TX 100 Mbps 10BASE-T 10 Mbps Number of cascade 1000BASE-T Consult the manufacturer of the repeater hub used.

  • Page 51: Function List

    Function list The following table shows the function list of a recorder module. For details on the functions, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Function Description Recording function To accumulate devices and labels sampled in a CPU module, and output them and an event history of the CPU module to a recording file and save the file to a save destination specified in the recording setting when a file saving trigger is satisfied.

  • Page 52: Sd Memory Card

    SD memory card The following shows an SD memory card used for a recorder module. Supported SD memory cards (sold separately) The following table shows the supported SD memory cards. When using an SD memory card, make sure to refer to the following: (Page 53 Considerations for using an SD memory card) Model name Capacity...
  • Page 53 Methods for stopping file access The following are the methods for stopping file access. Whether an SD memory card is being accessed such as when a recording file is being saved can be checked with the CARD ACS LED. • Switch operation on the front of a module •...

  • Page 54: Insertion Procedure

    Insertion/removal method of an SD memory card Make sure to stop file access when removing or replacing an SD memory card. If the power is turned OFF or a module is reset while a file is being accessed, the file may be corrupted. Insertion procedure Insert an SD memory card (1) straight into the SD memory card slot with its cutout pointed down.

  • Page 55: Write Protect Switch

    Considerations for using an SD memory card The following shows the considerations for using an SD memory card. Creating files/folders on an SD memory card Do not insert an SD memory card used for the recording function in a device such as a personal computer to directly edit or create files and folders.

  • Page 56: Ethernet Cable

    Ethernet cable The following shows the Ethernet cables that can be connected to a recorder module. Connectable Ethernet (twisted pair) cables (sold separately) The Ethernet cables compliant with IEEE802.3 1000BASE-T/100BASE-TX/10BASE-T standards can be used. Type Unshielded twisted pair cable (UTP cable) Shielded twisted pair cable (STP cable) Straight cable Crossover cable...

  • Page 57: Wiring Precautions

    Wiring precautions • To establish a reliable system and fully use the functions of a module, a wiring that does not easily receive the effects of noise is required. • Sufficient safety measures must be taken when constructing the IEEE802.3 1000BASE-T/100BASE-TX/10BASE-T networks.

  • Page 58: External Dimensions

    External dimensions The following figures show the external dimensions of a recorder module. 27.8 (Unit: mm) 5 SYSTEM CONFIGURATION 5.3 Recorder Module...

  • Page 59: Camera Recorder Module

    Camera Recorder Module This section explains a camera recorder module. For details on the functions, module labels, input/output signals, and buffer memory of a camera recorder module, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Part names The following shows the part names of a camera recorder module.
  • Page 60 Name Description SD/RD LED Indicates the data sending/receiving status in Ethernet. • ON: Being sent/received • OFF: Not being sent/received Ethernet port A port for connecting a camera recorder module to 10BASE-T/100BASE-TX/1000BASE-T. (A camera recorder module distinguishes among 10BASE-T, 100BASE-TX, and 1000BASE-T depending on an external device.) SD memory card lock switch (SD A switch for disabling access to an SD memory card to remove it.

  • Page 61: Hardware Specifications

    Hardware specifications The following table shows the hardware specifications of a camera recorder module. Item Specification Ethernet port Interface • 1000BASE-T • 100BASE-TX • 10BASE-T Data transmission speed 1000BASE-T 1 Gbps 100BASE-TX 100 Mbps 10BASE-T 10 Mbps Number of cascade 1000BASE-T Consult the manufacturer of the repeater hub used.

  • Page 62: Function List

    Function list The following table shows the function list of a camera recorder module. For details on the functions, refer to the following: MELSEC iQ-R System Recorder User's Manual (Application) Function Description Recording function To accumulate data (devices and labels) sampled in a CPU module and video data delivered from a network camera, and save them and an event history of the CPU module as a recording file when a file saving trigger is satisfied.

  • Page 63: Sd Memory Card

    SD memory card An SD memory card used for a camera recorder module is the same as a recorder module. Page 50 SD memory card Ethernet cable An Ethernet cable connected to a camera recorder module is the same as a recorder module. Page 54 Ethernet cable Network camera The following shows a network camera connected to a camera recorder module.

  • Page 64: Appendix

    APPENDIX Appendix 1 Considerations for the Firmware Update Function This section shows the considerations when using the firmware update function. Availability of the firmware update methods The firmware update method differs depending on whether the firmware versions before and after an update support the method using an engineering tool.
  • Page 65 MEMO APPX Appendix 1 Considerations for the Firmware Update Function...

  • Page 66: Index

    INDEX ....57 Camera recorder module ..... . . 54,61 Ethernet cable .
  • Page 67 MEMO...

  • Page 68: Revisions

    Japanese manual number: SH-082278-H This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 69: Warranty

    WARRANTY Please confirm the following product warranty details before using this product. 1. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be repaired at no cost via the sales representative or Mitsubishi Service Company.

  • Page 70: Information And Services

    INFORMATION AND SERVICES For further information and services, please contact your local Mitsubishi Electric sales office or representative. Visit our website to find our locations worldwide. MITSUBISHI ELECTRIC Factory Automation Global Website Locations Worldwide www.MitsubishiElectric.com/fa/about-us/overseas/ TRADEMARKS ONVIF is a trademark of Onvif, Inc.
  • Page 72 SH(NA)-082279ENG-I(2504)KWIX MODEL: SYSRECORDER-U-IN-E HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS: 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA 461-8670, JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission. Specifications subject to change without notice.
