2.5 Types of UPS Cabinet

For HV version, there are 2 models of UPS cabinets. There is no battery compartments for all these
models. The battery has to be connected externally (S versions).
Please consider the external battery space and wiring gauge for installation.
Cabinet Height
Switch Unit
STS
Max. Power Module
Power max.
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - hotline@infosec.fr – 03 17 AA 59 201 24
Mod5T 80/20 S HV
1
1
4
80 kVA
Mod5T 120/20 S HV
30U
1
1
6
120 kVA
9
