2.7 Internal Mechanisms
2.7.1 Breakers
After opening the front door, you can see there are three breakers, Main Breaker (Q1),
Maintenance Breaker (Q2) and Output Breaker (Q3).
Figure 2-11 Front Breakers
14
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - hotline@infosec.fr – 03 17 AA 59 201 24
