Extra Comm. Slot; Local Communication Ports - Rs232 & Usb; Snmp Slot - INFOSEC Mod5T User Manual

Table 5-3: Description of Battery Cabinet Temperature Detection Port
Name
SCL
SDA
+3.0V
Power GND

5.2 Extra Comm. Slot

There is an optional card, Extra Comm. Card which can be inserted into this slot. This option can
enhance the communication capability of the modular UPS. It provides an additional SNMP Slot,
Dry contact I/P & O/P signals and temperature sensors ports.
5.3 Local Communication Ports – RS232 & USB
Note: The RS232 and USB ports can't work simultaneously.

5.4 SNMP Slot

The SNMP card or AS400 card can be inserted into this slot to work with the UPS.
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com
Hot Line – Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)240 94 29 51 - hotline@infosec.fr – 03 17 AA 59 201 24
Position
X6.1 I²C communication SCL Signal
X6.2 I²C communication SDA Signal
X6.3 3V
X6.4 GND
Description
75
