Overview; Maximal Rack Mount Series Configuration Chart; Specifications - Altronix Maximal1RD Installation Manual

Altronix Maximal Rack Mount Series units distribute and switch power to access control systems and acces-
sories . They convert a 115VAC, 50/60Hz input into eight (8) or sixteen (16) independently controlled 12VDC
and/or 24VDC PTC protected outputs . Outputs are activated by an normally open (NO) or normally closed (NC)
dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc . Units will route
power to a variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door
Holders, etc . Outputs will operate in both Fail-Safe and/or Fail-Secure modes . The FACP Interface enables
Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices . The fire alarm discon-
nect feature is individually selectable for any or all of the outputs (see chart below) .

Maximal Rack Mount Series Configuration Chart:

Altronix Supply 1
Model Number (8 outputs)
12VDC @ 4A
Maximal1RHD
24VDC @ 3A
12VDC @ 4A
Maximal1RD
24VDC @ 3A
12VDC @ 6A
Maximal3RHD
24VDC @ 6A
12VDC @ 6A
Maximal3RD
24VDC @ 6A
12VDC @ 6A 12VDC @ 6A
Maximal33RD 24VDC @ 6A 24VDC @ 6A
12VDC @ 6A 24VDC @ 6A
Inputs:
• Normally closed [NC] or normally open [NO]
dry contact inputs (switch selectable) .
Outputs:
• Individually selectable Mag Lock/Strike (Fail-Safe,
Fail-Secure) solid state PTC protected power outputs .
• Thermal and short circuit protection with auto reset .
Fire Alarm Interface:
• Fire Alarm disconnect (latching with reset or
non-latching) is individually selectable for any or
all of the outputs .
• Remote reset capability for latching Fire Alarm
Interface mode .
• Fire Alarm disconnect input options:
a) Normally open [NO] or normally closed [NC]
dry contact input .
b) Polarity reversal input from
FACP signaling circuit .
Visual Indicators:
• Individual Output Status LEDs located on the
front panel .
Maximal Rack Access Power Controllers (PTC)
Power Power
Supply 2
(8 outputs)
N/A
N/A
N/A
N/A
N/A
N/A
N/A

Overview:

PTC
Protected
Total Auto-
Output Resettable
Current Outputs
4A
8
3A
4A
16
3A
6A 8
6A 16
12A 16

Specifications:

Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries
(A separate enclosure is required for batteries) .
• Maximum charge current 0 .7A .
• Automatic switch over to stand-by battery
when AC fails .
• Zero voltage drop when unit switches over to
battery backup (AC failure condition) .
Supervision:
• AC fail supervision (form "C" contact) .
• Low battery supervision (form "C" contact) .
Additional Features:
• Removable terminal blocks with locking
screw flange .
• 3-wire line cord .
• Illuminated master power disconnect
circuit breaker with manual reset .
Rack Dimensions (H x W x D):
3 .25" x 19 .125" x 8 .5"
(82 .6mm x 485 .8mm x 215 .9mm) .
Maximum 115VAC
Current 50/60Hz
Per Input
ACM8CBR-M (current
Output draw)
2 .0A 1 .9A
2 .0A 1 .9A
2 .0A 1 .9A
2 .0A 1 .9A
2 .0A 3 .8A
Power
Supply
Board
Input Fuse
Rating
5A/250V
5A/250V
3 .5A/250V
3 .5A/250V
3 .5A/250V
- 3 -
