Altronix MaximalFD Access Power/Controllers distribute and switch power to access control systems and

accessories. They convert a 120VAC 60Hz input into sixteen (16) independently controlled 12VDC or 24VDC

PTC protected protected outputs. The outputs are activated by an open collector sink or normally open (NO)

dry trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc. Units will route power to

a variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders,

etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary

devices. The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs.

All interconnecting equipment must be UL Listed.

Altronix

Model

Number

Maximal3FD

3.5A

Maximal5FD

3.5A

Maximal7FD

4.5A

These units are classified as Class 2 Power-Limited stand alone power supplies with stand-by battery and they are

suitable to power: sensors, electro-mechanical devices (e.g. electric door strikes).

UL Listings for

US Installations:

*ANSI/UL 294 7th Ed. Access Control Performance Levels:

Destructive Attack - I; Endurance - I; Line Security - I; Stand-by Power - II, III, IV.

UL Listings for

Canadian Installations:

ULC-S319-05 Electronic Access Control Systems will be invalidated through the use of any add-on, expansion,

memory or other module manufactured by the manufacturer or other manufacturers.

Maximal3FD/5FD/7FD Series (PTC) Installation Guide
