Altronix MaximalFDV Access Power/Controllers distribute and switch power to access control systems and acces-

sories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) independently

controlled 12VDC or 24VDC PTC protected outputs. The outputs are activated by an open collector sink or normally

open (NO) dry trigger input from an Access Control System, Keypad, Push Button, REX PIR, etc. Units will route

power to a variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door

Holders, etc. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other

auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs.

MaximalFDV Series Configuration Chart:

Nominal DC Output Voltage

9.7-

Maximal3FDV

13.2

9.7-

Maximal5FDV

13.2

Maximal7FDV

–

These units are suitable to power: sensors, electro-mechanical devices (e.g. electric door strikes).

ACM8CB Access Power Controller Modules:

• Sixteen (16) independently trigger controlled outputs. Output options:

a) Sixteen (16) Fail-Safe filtered power outputs.

b) Sixteen (16) Fail-Secure filtered power outputs.

c) Any combination of the above.

• Sixteen (16) Access Control System trigger inputs. Input trigger options:

a) Sixteen (16) normally open (NO) dry trigger inputs.

b) Sixteen (16) open collector inputs.

c) Any combination of the above.

• Sixteen (16) unswitched filtered aux. power outputs (outputs are rated @ 2.5A).

• Red LEDs on ACM8CB board indicate individual outputs are triggered (relays energized).

• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the

sixteen (16) outputs.

Fire Alarm disconnect input trigger options:

a) Normally open (NO) or normally closed (NC) dry trigger input.

b) Polarity reversal input from FACP signaling circuit.

• Green LED on ACM8CB board indicates FACP disconnect is triggered.

• FACP output relay indicates that FACP input is triggered (form "C" contact rated @ 1A/28VDC).

• eFlow Power Supply/Charger board provides common power for both ACM8CB Access Power Controller

boards (factory wiring) and all connected access control devices (field wiring).

• ACM8CB board main fuses are rated @ 10A. Output PTCs are rated @ 2.5A.

Maximal3FDV/5FDV/7FDV Series (PTC) Installation Guide
