Maximal FV Series
Dual Power Supply
Access Power Controllers (PTC)
Models Include:
Maximal11FDV
- Power Supply 1:
12VDC @ 3.3A or 24VDC @ 3.6A.
- Power Supply 2:
12VDC @ 3.3A or 24VDC @ 3.6A.
- Sixteen (16) PTC protected outputs.
Maximal33FDV
- Power Supply 1:
12VDC @ 5.3A or 24VDC @ 5.6A.
- Power Supply 2:
12VDC @ 5.3A or 24VDC @ 5.6A.
- Sixteen (16) PTC protected outputs.
Installation Guide
Rev. MFFDV031115
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
Maximal55FDV
- Power Supply 1: 12VDC @ 9.3A.
- Power Supply 2: 12VDC @ 9.3A.
- Sixteen (16) PTC protected outputs.
Maximal75FDV
- Power Supply 1: 12VDC @ 9.3A.
- Power Supply 2: 24VDC @ 9.6A.
- Sixteen (16) PTC protected outputs.
Maximal77FDV
- Power Supply 1: 24VDC @ 9.6A.
- Power Supply 2: 24VDC @ 9.6A.
- Sixteen (16) PTC protected outputs.
More than just power.
TM
Advertisement
Related Manuals for Altronix FV Series
Summary of Contents for Altronix FV Series
- Page 1 Maximal FV Series Dual Power Supply Access Power Controllers (PTC) Models Include: Maximal11FDV Maximal55FDV - Power Supply 1: - Power Supply 1: 12VDC @ 9.3A. 12VDC @ 3.3A or 24VDC @ 3.6A. - Power Supply 2: 12VDC @ 9.3A. - Power Supply 2: - Sixteen (16) PTC protected outputs.
-
Page 2: Table Of Contents
Table of Contents: MaximalFDV Series Overview ..........pg. 3 MaximalFDV Series Configuration Chart . -
Page 3: Maximalfdv Series Overview
MaximalFDV Series Overview: Altronix MaximalFDV Access Power/Controllers distribute and switch power to access control systems and acces- sories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) independently controlled 12VDC or 24VDC PTC protected outputs. Outputs are activated by an open collector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. -
Page 4: Maximal Series Features
MaximalFDV Series Features: ACM8CB Access Power Controller Modules: • Sixteen (16) independently trigger controlled outputs. Output options: a) Sixteen (16) Fail-Safe filtered power outputs. b) Sixteen (16) Fail-Secure filtered power outputs. c) Any combination of the above. • Sixteen (16) Access Control System trigger inputs. Input trigger options: a) Sixteen (16) normally open (NO) dry trigger inputs. -
Page 5: Maximalfdv Installation Instructions
MaximalFDV Installation Instructions: Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, the Canadian Electric Code, Part I, Part II and with all local codes and authorities having jurisdiction. Product is intended for indoor use only. Power Supply Board LED Diagnostics (pg. - Page 6 8. ACM8CB Fire Alarm Interface options (Figs. 5-9, pg. 12): A normally closed [NC] or normally open [NO] input trigger from a fire alarm control panel or a polarity reversal input from an FACP signaling circuit will affect selected outputs. To enable FACP Disconnect for an output turn the corresponding switch(es) [SW1-SW8] OFF on each ACM8CB board.
-
Page 7: Maintenance
Maintenance: Unit should be tested at least once a year for the proper operation as follows: FACP Supervision: To ensure proper connection and operation of the Fire Alarm disconnect hookup. Please follow the appropriate procedure below: Normally Open Input: Placing a short between terminals marked [T] and [+ INP] will trigger the Fire Alarm Disconnect. -
Page 8: Power Supply Board Terminal Identification
Power Supply Board Terminal Identification: Terminal Legend Function/Description Connect 220VAC, 50/60Hz to these terminals: L to hot, N to neutral. L, N Do not use terminal marked [G]. + DC – Factory connected to ACM8CB board. Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be Supervised normally open, normally closed from an FACP output circuit (Fig. -
Page 9: Power Supply Board Output Voltage Settings
Power Supply Board Output Voltage Settings: Fig. 1a OFF - 24V ON - 12V Access Power Controller Typical Application Diagram (for each ACM8CB): Fig. 2 Fig. 2a Intact = Dry Input Normally Open (N.O.) Cut = Wet Input Door Releasing FACP FACP Device... -
Page 10: Maximalfdv Battery Hookup And Tamper Switch Installation
Fig. 3 - Maximal FDV Series Tamper Switch OFF - 24V ON - 12V Power Supply Board AC DC NC C NO NC C NO TRIGGER +AUX- AC FAIL BAT FAIL SUPERVISED RESET Line Neutral Ground OFF - 24V ON - 12V Power Supply Board AC DC... -
Page 11: Nec Power-Limited Wiring Requirements
NEC Power-Limited Wiring Requirements: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below. -
Page 12: Facp/Optional Power Supply Hook-Up Diagrams
FACP Hook-Up Diagrams: Fig. 5 Optional hook-up using two (2) isolated Fig. 6 Polarity reversal input from FACP power supply inputs (Only applicable on signaling circuit output (polarity is Maximal11FDV, not evaluated by UL): referenced in alarm condition): CUT JUMPERS JUMPER J1 AND J2 FACP... - Page 13 Notes: Maximal11FDV/33FDV/55FDV/75FDV/77FDV Series Installation Guide - 13 -...
- Page 14 Notes: - 14 - Maximal11FDV/33FDV/55FDV/75FDV/77FDV Series Installation Guide...
-
Page 15: Enclosure Dimensions
(21.6mm) 4” (101.6mm) 2” (50.8mm) 19” (482.6mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIMaximal11FDV/33FDV/55FDV/75FDV/77FDV Series... - Page 16 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
