MaxFit E Series Dual Power Supply Expandable Power Systems Models Include: MaxFit11E MaxFit37E - Power Supply 1:12VDC @ 4A or 24VDC @ 3A. - Power Supply 1: 24VDC @ 10A. - Power Supply 2: 12VDC @ 4A or 24VDC @ 3A. - Power Supply 2: 12VDC or 24VDC @ 6A.
Page 2
MaxFit E Series Overview: Altronix MaxFit Expandable Power Systems provide system designers and installers with optimum power choices and the highest levels of versatility. They provide 12VDC, 24VDC, or 12VDC and 24VDC simultaneously via two (2) Suit of features includes AC fail, low battery, and battery presence monitoring.
Page 3
4. Measure output voltage before connecting devices. This helps avoiding potential damage. 5. Connect devices or Altronix sub-assembly modules to be powered to the terminals marked [– DC +] (Fig. 1h, pg. 5). Refer to page 2 for non power-limited applications.
Wiring: Use 18 AWG or larger for all low voltage power connections. Note: Take care to keep power-limited circuits separate from non power-limited wiring (115VAC, Battery). Maintenance: Unit should be tested at least once a year for the proper operation as follows: Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level...
Power Supply Board LED Diagnostics: Power Supply Status Red (DC) Green (AC) Normal operating condition. Loss of AC. Stand-by battery is supplying power. No DC output. Short circuit or thermal overload condition. No DC output. Loss of AC. Discharged battery. Red (Bat) Battery Status Normal operating condition.
Power Supply Board Stand-by Battery Specifications Altronix Power Supply 20 min. of 4 hr. of 24 hr. of 60 hr. of Model Board Battery Backup Backup Backup Backup AL400ULXB2 12VDC/40AH* 300mA (Refer to Fig. 2a on MaxFit11E pg. 4 for...
NEC Power-Limited Wiring Requirements: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits. One such example of this is shown below.
Page 8
1.25” (31.8mm) 1.25” (31.8mm) 7.00” (177.8mm) 7.00” (177.8mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IIMaxFit Expandable 2 P/S Series...
