Expandable Power Systems
Installation Guide
Models Include:
Maximal11E
- Power Supply 1:
12VDC @ 4A or 24VDC @ 3A.
- Power Supply 2:
12VDC @ 4A or 24VDC @ 3A.
Maximal33E
- Power Supply 1:
12VDC or 24VDC @ 6A.
- Power Supply 2:
12VDC or 24VDC @ 6A.
Maximal37E
- Power Supply 1:
24VDC @ 10A.
- Power Supply 2:
12VDC or 24VDC @ 6A.
Maximal75E
- Power Supply 1:
12VDC @ 10A.
- Power Supply 2:
24VDC @ 10A.
Rev. ME052119
Altronix Corp.
140 58th St. Brooklyn, NY
Maximal13E
- Power Supply 1:
12VDC or 24VDC @ 6A.
- Power Supply 2:
12VDC @ 4A or 24VDC @ 3A.
Maximal35E
- Power Supply 1:
12VDC @ 10A.
- Power Supply 2:
12VDC or 24VDC @ 6A.
Maximal55E
- Power Supply 1:
12VDC @ 10A.
- Power Supply 2:
12VDC @ 10A.
Maximal77E
- Power Supply 1:
24VDC @ 10A.
- Power Supply 2:
24VDC @ 10A.
