Altronix MaximalDV Access Power/Controllers distribute and switch power to access control systems and acces-

sories. They convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into sixteen (16) independently

controlled 12VDC or 24VDC PTC protected outputs. These Fail-Safe/Fail-Secure power outputs may be converted

to dry form "C" contacts. The outputs are activated by an open collector sink or normally open (NO) dry trigger

input from an Access Control System, Keypad, Push Button, REX PIR, etc. Units will route power to a variety of

access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders, etc. The FACP

Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire

alarm disconnect feature is individually selectable for any or all of the sixteen (16) outputs.

Altronix

Power Supply 1 Power Supply 2

Model Number

AL400XB2V

12VDC @ 3.5A

Maximal11DV

12VDC @ 2.7A

24VDC @ 3.5A

AL600XB220

12VDC @ 5.5A

Maximal33DV

12VDC @ 5.7A

24VDC @ 5.5A

AL1012XB220

Maximal55DV

12VDC @ 9.5A

AL1012XB220

Maximal75DV

12VDC @ 9.5A

AL1024XB2V

Maximal77DV

24VDC @ 9.7A

• Sixteen (16) independently trigger controlled outputs.

Output options:

a) Sixteen (16) Fail-Safe filtered and electronically regulated power outputs.

b) Sixteen (16) Fail-Secure filtered and electronically regulated power outputs.

c) Sixteen (16) form "C" relay outputs (rated @ 5A/28VDC or VAC).

d) Any combination of the above.

• Sixteen (16) Access Control System trigger inputs.

Input trigger options:

a) Sixteen (16) normally open (NO) dry trigger inputs.

b) Sixteen (16) open collector inputs.

c) Any combination of the above.

• Sixteen (16) unswitched filtered and electronically regulated aux. power outputs (outputs are rated @ 2.5A).

• Red LEDs on ACM8CB board indicate individual outputs are triggered (relays energized).

• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the sixteen (16) outputs.

Fire Alarm disconnect input trigger options:

a) Normally open (NO) or normally closed (NC) dry trigger input.

b) Polarity reversal input from FACP signaling circuit.

• Green LED on ACM8CB board indicates FACP disconnect is triggered.

• FACP output relay indicates that FACP input is triggered (form "C" contact rated @ 1A/28VDC).

Maximal11DV / Maximal33DV / Maximal55DV / Maximal75DV / Maximal77DV Access Power Controllers (PTC) Installation Guide
