Overview; Specifications; Features - Altronix eFLOW Series Installation Manual

Altronix eFlowNBV power supply/chargers convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz
input to a 12VDC or 24VDC output .
Altronix
Model Nuber 220VAC 50/60Hz
eFlow3NBV
eFlow4NBV
eFlow6NBV
eFlow102NBV
eFlow104NBV
All of the above Power Supply/Chargers can be installed in Trove1 and Trove2 Access and Power Integration
Systems and Maximal Series .
Agency Listings:
• CE European Conformity .
Output:
• Overvoltage protection .
• Filtered and electronically regulated outputs .
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries .
• Automatic switch over to stand-by battery when
AC fails .
• Transfer to stand-by battery power is instantaneous
with no interruption .
Fire Alarm Disconnect:
• Supervised Fire Alarm disconnect (latching or non-
latching) 10K EOL resistor . Operates on a normally
open (NO) or normally closed (NC) trigger .
eFlowNBV - Power Supply/Chargers
Output Voltage (Current)
Input Rating
12VDC
2 .1A
2 .1A
2 .1A
2 .1A
3 .1A

Overview:

Specifications:

24VDC
2A 2A
4A 4A
6A 6A
10A –
– 10A

Features:

Supervision:
• AC fail supervision (form "C" contacts) .
• Battery fail and presence supervision
(form "C" contacts) .
• Low power shutdown . Shuts down DC output
terminals if battery voltage drops below 80% of
nominal . Prevents deep battery discharge .
Visual Indicators:
• Green AC Power LED indicates 220VAC present .
• AC input and DC output LED indicators .
Additional Features:
• Short circuit and overload protection .
Board Dimensions (approximate L x W x H):
eFlow3NBV, eFlow4NBV,
eFlow6NBV, eFlow102NBV:
7 .5" x 4 .6" x 1 .75" (190 .5mm x 116 .8mm x 44 .5mm)
eFlow104NBV:
8 .25" x 4 .56" x 1 .5"
(209 .5mm x 115 .8mm x 38 .1mm) .
Maximum
Aux. Output Charge
(unswitched) Current
1A
1A
1A
1A
1A
1 .54A
1 .54A
1 .54A
1 .54A
1 .54A
- 3 -
