Wiring Diagram - Directed 403.VW10 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
VESCM
(under drivers dash or below glove box)
E F
D2D Port
(+) Ignition Input/Output
(-) Ground
(-) Ground
(+) Starter Output
(AC) Tach Input
(-) Hood Pin Input
(+) 12V Input
VESCM Connector L
(under driver's dash or behind glove box)
10
6 4
2
3 1
6 403.VW10 2.00 2008 Volkswagen GTI
©2022 VOXX•DEI LLC. All rights reserved.
1 2 3 4 5 6
(+) Starter:
G plug at VESCM
Red/Black or
(under driver's dash
Red/Brown, 10 12
7 8 9 11
or below glove box)
pin 1
G
H
FT CAN High: Orange/Green, pin 8
FT CAN Low:Orange/Brown, pin 7
Hood Pin
2
(+)12V:
1
Red/Black, pin 1
2
HS CAN High:
Orange/Black, pin 6
1
9
HS CAN Low:
Orange/Brown, pin 14
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
FT CAN High: Orange/Green: 5
FT CAN Low: Orange/Brown: 6
(+) Parking Light Output: Brown: 7
Parking Lights Interr. (veh. side): Yellow: 8
Parking Lights Interr. (conn. side): Orange/Yellow: 9
Key Wrap: Orange/Red: 10
Key Wrap: Yellow/Red 11
Key Wrap: Brown/Red: 12
(AC) Tach Output: Violet/White: 5
CUT
Parking Lights Interr.:
Red/White, pin 8
Headlight switch
6
10 6
8
(black conn. at
light switch)
5 1
3
(+) Parking Lights:
Gray/Yellow, pin 3
).
OBDII
8
Diagnostic Connector
16
XKD2D65
(+) 12V
TX
(-) Ground
RX
