Vehicle Connections - Directed 403.VW10 Installation Manual

Vehicle connections

The connection information listed below is specific to the 2008 Volkswagen GTI. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
10 403.VW10 2.00 2008 Volkswagen GTI
©2022 VOXX•DEI LLC. All rights reserved.
Description
No Connection
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
(DATA) FT CAN High
(DATA) FT CAN Low
Relay N.O. Pk Light Output
Relay COM Pk Light Interrupt
Relay N.C. Pk Light Interrupt
Relay N.C. Key Wrap
Relay COM Key Wrap
Relay N.O. Key Wrap
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
(-) Hazard Light Output
(-) Trunk Output
(-) W2W Only - Door / Trunk Output
(-) W2W Only - E-Brake Output
[1]
(AC) W2W Only - Tach Output
(+) W2W Only - Brake Output
No Connection
No Connection
(MUX) Door Lock Toggle Output
No Connection
No Connection
(-) W2W Only - Hood Output
Description
Connects To
Wire Location
No Connection
No Connection
OBD-Data Link Connector, black 16 pin plug, pin 6
OBD-Data Link Connector, black 16 pin plug, pin 14
Steering Column Module, black 20 pin plug, pin 14
Steering Column Module, black 20 pin plug, pin 15
Headlight Switch, black 10 pin plug, pin 3
Headlight Switch, black 10 pin plug, pin 8
Headlight Switch, black 10 pin plug, pin 8
Immobilizer Reader Coil on ignition switch, black 2 pin plug, pin 1
Immobilizer Reader Coil on ignition switch, black 2 pin plug, pin 1
Immobilizer Reader Coil on ignition switch, black 2 pin plug, pin 1
VESCM-Relay Box under driver dash, black 2 pin plug (L), pin 1
Connects To
Wire Location
VESCM-Relay Box under driver dash, black 12 pin plug (G), pin 9
Driver Door Module, white 32 pin plug, pin 30
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
Driver Door Module, black 20 pin plug, pin 16
No Connection
No Connection
Remote Starter
Connects To
Wire Location
(+/-) Wire Color
Data Orange/Black (DIAG CAN)
Data Orange/Brown (DIAG CAN)
Data Orange/Green
Data Orange/Brown
+ Gray/Yellow
Cut Red/White
Cut Red/White
RF Blue
RF Blue
RF Blue
+ Red/Black (40A)
(chassis ground)
(+/-) Wire Color
- Brown/Red
- Blue
- Green/White (key lock)
(+/-) Wire Color
