  • Page 1 403.HONDA9 v2.07 2023 Honda Civic (Smart Key)

  • Page 2: Table Of Contents

    Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Wiring diagram Locating components in the vehicle Vehicle connections Module programming Module programming for convenience only (skip transponder) Connecting the module LED diagnostics and troubleshooting Soft reset Hard reset Feature programming Feature and option list Limited one year consumer warranty Quick Reference Guide (customer copy)

  • Page 3: Introduction

    Introduction DB3 is an all-in-one door lock and override module. Warning! This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.HONDA9 2.07 2023 Honda Civic (Smart Key)

  • Page 4: Vehicle Function Compatibilities

    Control of aftermarket alarm with OEM remote Brake Status (foot brake) Key2GO Door Locks Status Immobilizer Bypass-Data No Key Req'd E-Brake Status RAP Shut Down (Retained ACC Power) Ignition Status SmartStart 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 5: Pre-Installation And Application Warnings

    [2] Tach: An optional connection required on some remote starters, which do not support a tach signal in D2D. [3] PTS: The PTS wire is mandatory in vehicles equipped with a manual transmission; otherwise it is ONLY required for PitStop/Idle mode shutdown. 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 6: Wiring Diagram

    (above or behind dash fuse box) (brown conn. above or behind dash fuse box) (+) Accessory: Gray, pin 56 (+) Ignition: Violet, pin 57 (-) PTS: Yellow or Gray, pin 66 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 7: Locating Components In The Vehicle

    Locating components in the vehicle 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 8: Vehicle Connections

    BCM behind dash fuse box, white 66 pin plug (A), pin 33 Data Lt. Blue (S-NET) H2/11 Orange/Black No Connection No Connection H2/12 Blue/Red No Connection No Connection 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.
  • Page 9 BCM behind dash fuse box, brown 66 pin plug (C), pin 45 White Tachometer [2] Camshaft Position Sensor, engine driver side front, 3 pin plug, pin 3 Lt. Violet/White (2.0L) 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 10: Module Programming

    When the LED turns solid red, start the vehicle. The LED will turn ON solid green for 3 seconds then shuts off. You have successfully completed the module programming sequence. 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 11: Module Programming For Convenience Only (Skip Transponder)

    Release x5 Key IN START Turn ignition ON and wait until the LED turns OFF. Key OUT Turn ignition OFF. START You have successfully completed the module programming sequence. 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 12: Connecting The Module

    (12-pin) (D2D) (10-pin) (14-pin) W2W installation If required: Connect the 10-pin and 12-pin harnesses to the module, then connect the 14-pin harness to the module. (12-pin) (10-pin) (14-pin) 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 13: Led Diagnostics And Troubleshooting

    External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.
  • Page 14 The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 15: Soft Reset

    Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the & LED starts to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Release Solid 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 16: Feature Programming

    To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 17: Feature And Option List

    3. No Trunk Release When Trunk button is pressed on the transmitter, the motorized hatch & trunk release. 1. Disabled* Disable takeover. Takeover Option 2. Enabled Enable takeover. 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 18: Limited One Year Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.

  • Page 19: Quick Reference Guide (Customer Copy)

    For Manual Transmission, press and hold the clutch first, then depress the brake pedal for a minimum 3 seconds. * Icon and remote appearance may differ depending on the model purchased. 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.
  • Page 20 Press & hold for 1 second to remote start. * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. Notes 403.HONDA9 2.07 2023 Honda Civic (Smart Key) ©2023 Directed. All rights reserved.
