Directed 403.VW10 Installation Manual page 11

Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Brake Wire
Ignition
Starter
11 403.VW10 2.00 2008 Volkswagen GTI
©2022 VOXX•DEI LLC. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
No Connection
No Connection
No Connection
(+) Pk Light Input
(+) W2W Only - Starter Input
(+) W2W Only - Ignition Input
(-) W2W Only - Ground When Running (Status) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
VESCM-Relay Box under driver dash, black 2 pin plug (L), pin 1
VESCM-Relay Box under driver dash, black 16 pin plug (E), pin 2
Steering Column Module, black 20 pin plug, pin 17
Steering Column Module, black 20 pin plug, pin 18
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
Remote Starter
Remote Starter
Remote Starter
Remote Starter
(+/-)
+
+
+
+
(+/-) Wire Color
Description
Description
No Connection
No Connection
Wire Color
Red/Black (40A)
Black/Red (test with ignition on)
Black
Red/Black or Red/Brown
