Remote Label Dispenser (RLD)

Introducing the RLD
The Remote Label Dispenser (or RLD) is an external printing element dedicated to print
indicia on thermal self-adhesive paper with various widths.
Feed Button
Led
The 2 LED (green and yellow) are combined to give the status of the RLD as follows:
Led
Off
Solid Green
Solid Amber
Flashing Green
Flashing Red
Double Flashing Green
Flashing Amber
Alternately Flashing Green and Red
Flashing Red, Red and Green
Flashing Red, Amber Green
Wakes-up or Sleeps the RLD.
Indicates RLD Status.
Meaning
RLD Power OFF.
RLD is on and in an idle state
Error, power off/on and retry
RLD is receiving data
Media is out or printhead is open
RLD is paused
RLD print head is over temperature
Error, call support
Error, call support
Memory Defragmentation, Do Not reset
or turn off power!
