1. INST:NSEL 6
2. SYST:BAUD 9600
3. SYST:INT RS232
Update PC terminal software parameters as follows:
Port: RS232, According to Device Manager (refer to Figure 1–11 for an example of COM5).
Baud rate: 9600.
Following commands are sent via RS232 communication interface.
4. INST:NSEL 6
5. SYST:LANG GEN
There are differences between
Genesys power supply series GEN language commands. Verify commands-set used by PC
software meets
1.9.8

Reset Blank Front Panel Power Supply to Default Settings

power supply default settings are described in section 2.13.1. In case of communication
failure (or unknown communication settings), press and hold Reset Button (refer to
number 5) located on the rear panel for five to ten seconds and release. Power supply settings will
be set according to
(power supply with address 6 will receive commands).
(switch baud rate to 9600).
(switch communication interface to RS232 interface).
(power supply with address 6 will receive commands).
(switch communication language to GEN language).
NOTE
power supply series GEN language commands to
power supply series (refer to section 4.9).
Table 2-6 Table 2-7
and .
22
Table 1-4
, item
