NANO-QM770 EPIC SBC
MODEL:
NANO-QM770
EPIC SBC with 3rd Generation 22nm Intel® Mobile CPU
Up to 8.0 GB DDR3, DVI, HDMI, LVDS, Dual GbE,
SATA 6Gb/s, USB 3.0, PCIe Mini, Intel® AMT, RoHS
User Manual
Page i
Rev. 1.04 – August 12, 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO-QM770-R10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology NANO-QM770-R10

Summary of Contents for IEI Technology NANO-QM770-R10

  • Page 1 NANO-QM770 EPIC SBC MODEL: NANO-QM770 EPIC SBC with 3rd Generation 22nm Intel® Mobile CPU Up to 8.0 GB DDR3, DVI, HDMI, LVDS, Dual GbE, SATA 6Gb/s, USB 3.0, PCIe Mini, Intel® AMT, RoHS User Manual Page i Rev. 1.04 – August 12, 2015...
  • Page 2 NANO-QM770 EPIC SBC Revision Date Version Changes August 12, 2015 1.04 Modified Table 2-2: Optional Items July 14, 2015 1.03 Modified Table 3-8: Front Panel Connector Pinouts April 23, 2014 1.02 Modified Table 3-24: LAN Pinouts December 9, 2013 1.01 Updated Appendix D: Digital I/O Interface May 24, 2012 1.00...
  • Page 3 NANO-QM770 EPIC SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 NANO-QM770 EPIC SBC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product. NOTE These messages inform the reader of essential but non-critical information.

  • Page 5: Table Of Contents

    NANO-QM770 EPIC SBC Table of Contents 1 INTRODUCTION......................1 1.1 I ......................2 NTRODUCTION 1.2 B ........................2 ENEFITS 1.3 F ........................2 EATURES 1.4 C ......................3 ONNECTORS 1.5 D ....................... 5 IMENSIONS 1.6 D ........................ 6 1.7 T ..................
  • Page 6 NANO-QM770 EPIC SBC 3.2.11 Power Connector (12V) ................. 27 3.2.12 RS-232 Serial Port Connectors (COM1, COM2) .......... 28 3.2.13 RS-422/485 Serial Port Connector (COM3)..........28 3.2.14 SATA Drive Connectors ................. 29 3.2.15 SATA Power Connectors ................30 3.2.16 SMBus Connector ..................31 3.2.17 SO-DIMM Connector..................
  • Page 7 NANO-QM770 EPIC SBC 4.7.3 SATA Drive Connection ................... 54 4.7.4 Single RS-232 Cable (w/o Bracket) ..............55 ® 4.8 I AMT S ................56 NTEL ETUP ROCEDURE 5 BIOS ..........................58 5.1 I ......................59 NTRODUCTION 5.1.1 Starting Setup....................59 5.1.2 Using Setup ......................
  • Page 8 NANO-QM770 EPIC SBC 5.7 E ......................... 90 6 SOFTWARE DRIVERS ....................92 6.1 A ................93 VAILABLE OFTWARE RIVERS 6.2 S ..................93 OFTWARE NSTALLATION 6.3 C ................95 HIPSET RIVER NSTALLATION 6.4 G ................98 RAPHICS RIVER NSTALLATION 6.5 LAN D ..................
  • Page 9 NANO-QM770 EPIC SBC List of Figures Figure 1-1: NANO-QM770.......................2 Figure 1-2: Connectors (Front)......................3 Figure 1-3: Connectors (Solder Side) ...................4 Figure 1-4: Dimensions (mm) ......................5 Figure 1-5: Data Flow Diagram......................6 Figure 3-1: Connector and Jumper Locations................15 Figure 3-2: Connector and Jumper Locations (Solder Side) ...........16 Figure 3-3: Audio Connector Location ..................18 Figure 3-4: Battery Connector Location..................19 Figure 3-5: Digital I/O Connector Location ................20...
  • Page 10 NANO-QM770 EPIC SBC Figure 3-26: HDMI Connector ......................38 Figure 4-1: SO-DIMM Installation ....................43 Figure 4-2: PCIe Mini Card Installation..................44 Figure 4-3: AT/ATX Mode Selection Jumper Location..............46 Figure 4-4: Clear CMOS Jumper Location .................47 Figure 4-5: Clear ME RTC Registers Jumper Location.............48 Figure 4-6: Flash Descriptor Security Override Jumper Location ..........48 Figure 4-7: LVDS Voltage Selection Jumper Location .............49 Figure 4-8: LVDS Resolution Selection Jumper Location............50...
  • Page 11 NANO-QM770 EPIC SBC Figure 6-21: Restart the Computer ..................106 Figure 6-22: SATA RAID Driver Welcome Screen ..............107 Figure 6-23: SATA RAID Driver License Agreement.............. 108 Figure 6-24: SATA RAID Driver Read Me File ................. 108 Figure 6-25: SATA RAID Driver Setup Operations ..............109 Figure 6-26: SATA RAID Driver Installation Finish Screen ...........
  • Page 12 NANO-QM770 EPIC SBC List of Tables Table 1-1: Technical Specifications....................8 Table 2-1: Packing List.........................12 Table 2-2: Optional Items......................13 Table 3-1: Peripheral Interface Connectors ................17 Table 3-2: Rear Panel Connectors ....................17 Table 3-3: Audio Connector Pinouts ..................18 Table 3-4: Battery Connector Pinouts ..................19 Table 3-5: Digital I/O Connector Pinouts..................20 Table 3-6: CPU Fan Connector Pinouts..................21 Table 3-7: System Fan Connector Pinouts ................22...
  • Page 13 NANO-QM770 EPIC SBC Table 4-1: Jumpers ........................45 Table 4-2: AT/ATX Mode Selection Jumper Settings ..............45 Table 4-3: Clear CMOS Jumper Settings..................47 Table 4-4: Clear ME RTC Registers Jumper Settings ...............47 Table 4-5: Flash Descriptor Security Override Jumper Settings..........48 Table 4-6: LVDS Voltage Selection Jumper Settings..............49 Table 4-7: LVDS Screen Resolution Jumper Settings ..............50 Table 4-8: PCIe Mini/mSATA Mode Selection Jumper Settings..........51 Table 5-1: BIOS Navigation Keys ....................60...
  • Page 14 NANO-QM770 EPIC SBC BIOS Menus BIOS Menu 1: Main ........................61 BIOS Menu 2: Advanced ......................62 BIOS Menu 3: ACPI Configuration ....................63 BIOS Menu 4: RTC Wake Settings ....................64 BIOS Menu 5: Trusted Computing ....................65 BIOS Menu 6: CPU Configuration ....................66 BIOS Menu 7: SATA Configuration .....................68 BIOS Menu 8: Intel(R) Rapid Start Technology .................69 BIOS Menu 9: Intel TXT(LT) Configuration ................70...

  • Page 15: Introduction

    NANO-QM770 EPIC SBC Chapter Introduction Page 1...

  • Page 16: Introduction

    NANO-QM770 EPIC SBC 1.1 Introduction Figure 1-1: NANO-QM770 The NANO-QM770 is an EPIC SBC with a 3 generation 22nm Intel® mobile CPU and Intel® QM77 Express Chipset. Storage on the board is handled by the SATA 6Gb/s ports for connecting a hard drive, optical drive or SSD. The PCIe Mini slot allows an mSATA card to be installed.

  • Page 17: Connectors

    NANO-QM770 EPIC SBC  EPIC form factor  RoHS compliant  Intel® AMT 8.0 support  Dual GbE  Supports HDMI, LVDS and DVI-I interface for triple independent display (HDMI V1.3a compliant)  Six USB ports (two USB 2.0, four USB 3.0) ...

  • Page 18: Figure 1-3: Connectors (Solder Side)

    NANO-QM770 EPIC SBC Figure 1-3: Connectors (Solder Side) Page 4...

  • Page 19: Dimensions

    NANO-QM770 EPIC SBC 1.5 Dimensions The main dimensions of the NANO-QM770 are shown in the diagram below. Figure 1-4: Dimensions (mm) Page 5...

  • Page 20: Data Flow

    NANO-QM770 EPIC SBC 1.6 Data Flow Figure 1-5 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-5: Data Flow Diagram Page 6...

  • Page 21: Technical Specifications

    NANO-QM770 EPIC SBC 1.7 Technical Specifications NANO-QM770 technical specifications are listed in Table 1-1. Specification NANO-QM770 Form Factor EPIC CPU Socket Socket G2 generation 22nm Intel® mobile CPU System Chipset Intel® QM77 Memory One 204-pin 1600/1333/1066 MHz DDR3 SO-DIMM supported (system max.

  • Page 22: Table 1-1: Technical Specifications

    NANO-QM770 EPIC SBC Two USB 2.0 (via pin header) USB Ports Four external USB 3.0 ports SMBus One 4-pin wafer connector Storage SATA Two independent SATA channels with 6Gb/s data transfer rates Environmental and Power Specifications Power Supply 12 V only, AT/ATX support Power Connector 1 x Internal 4-pin (2x2) power connector Power Consumption...

  • Page 23: Packing List

    NANO-QM770 EPIC SBC Chapter Packing List Page 9...

  • Page 24: Anti-Static Precautions

    NANO-QM770 EPIC SBC 2.1 Anti-static Precautions WARNING! Static electricity can destroy certain electronics. Make sure to follow the ESD precautions to prevent damage to the product, and injury to the user. Make sure to adhere to the following guidelines:  Wear an anti-static wristband: - Wearing an anti-static wristband can prevent electrostatic discharge.

  • Page 25: Packing List

    NANO-QM770 EPIC SBC 2.3 Packing List NOTE: If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-QM770 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.tw.

  • Page 26: Optional Items

    NANO-QM770 EPIC SBC Quantity Item and Part Number Image Utility CD One Key Recovery CD Quick installation guide Table 2-1: Packing List 2.4 Optional Items These optional items are available. Item and Part Number Image RS-422/485 cable (P/N: 32205-003800-300-RS) Dual USB cable (wo bracket) (P/N: 32000-044300-RS) KB/MS PS/2 Y-cable (P/N: 32000-023800-RS)

  • Page 27: Table 2-2: Optional Items

    NANO-QM770 EPIC SBC Item and Part Number Image Infineon TPM module (P/N: TPM-IN01-R11) Table 2-2: Optional Items Page 13...

  • Page 28: Connector Pinouts

    NANO-QM770 EPIC SBC Chapter Connector Pinouts Page 14...

  • Page 29: Peripheral Interface Connectors

    NANO-QM770 EPIC SBC 3.1 Peripheral Interface Connectors Section 3.1.1 shows peripheral interface connector locations. Section 3.1.2 lists all the peripheral interface connectors seen in Section 3.1.1. 3.1.1 Layout The figure below shows the on-board peripheral connectors, rear panel peripheral connectors and on-board jumpers. Figure 3-1: Connector and Jumper Locations Page 15...

  • Page 30: Peripheral Interface Connectors

    NANO-QM770 EPIC SBC Figure 3-2: Connector and Jumper Locations (Solder Side) 3.1.2 Peripheral Interface Connectors The table below shows a list of the peripheral interface connectors on the NANO-QM770. Detailed descriptions of these connectors can be found below. Connector Type Label Audio connector 10-pin header...

  • Page 31: External Interface Panel Connectors

    NANO-QM770 EPIC SBC Connector Type Label PCIe Mini card slot PCIe Mini card slot Power connector (12V) 4-pin connector PWR1 RS-232 serial ports (COM1, COM2) 10-pin header COM1, COM2 RS-422/485 serial port (COM3) 4-pin wafer COM3 SATA connectors SATA connector S_ATA1, S_ATA2 SATA power connectors 2-pin wafer...

  • Page 32: Internal Peripheral Connectors

    NANO-QM770 EPIC SBC 3.2 Internal Peripheral Connectors Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. This section has complete descriptions of all the internal, peripheral connectors on the NANO-QM770. 3.2.1 Audio Connector CN Label: AUDIO1...

  • Page 33: Battery Connector

    NANO-QM770 EPIC SBC 3.2.2 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. CN Label: BAT1 CN Type: 2-pin wafer, p=1.25mm CN Location: See Figure 3-4...

  • Page 34: Digital I/O Connector

    NANO-QM770 EPIC SBC 3.2.3 Digital I/O Connector CN Label: DIO1 10-pin header, p=2.00mm CN Type: CN Location: See Figure 3-5 CN Pinouts: See Table 3-5 The digital I/O connector provides programmable input and output for external devices. The digital I/O provides 4-bit output and 4-bit input. Figure 3-5: Digital I/O Connector Location Description Description...

  • Page 35: Fan Connector (System)

    NANO-QM770 EPIC SBC The fan connector attaches to a CPU cooling fan. Figure 3-6: CPU Fan Connector Location Description +V12S Rotation Signal PWM Control Signal Table 3-6: CPU Fan Connector Pinouts 3.2.5 Fan Connector (System) CN Label: SYS_FAN1 CN Type: 3-pin wafer, p=2.54mm CN Location: See Figure 3-7...

  • Page 36: Front Panel Connector

    NANO-QM770 EPIC SBC Description Rotation Signal +12V Table 3-7: System Fan Connector Pinouts 3.2.6 Front Panel Connector CN Label: F_PANEL1 CN Type: 10-pin header, p=2.54mm CN Location: See Figure 3-8 CN Pinouts: See Table 3-8 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 37: Keyboard/Mouse Connector

    NANO-QM770 EPIC SBC 3.2.7 Keyboard/Mouse Connector CN Label: KB_MS1 6-pin wafer, p=2.00mm CN Type: CN Location: See Figure 3-9 CN Pinouts: See Table 3-9 The keyboard/mouse connector connects to a PS/2 Y-cable that can be connected to a PS/2 keyboard and mouse. Figure 3-9: Keyboard/Mouse Connector Location Description VCC5_KBMS...

  • Page 38: Figure 3-10: Lvds Connector Location

    NANO-QM770 EPIC SBC CN Pinouts: See Table 3-10 The LVDS connector is for an LCD panel connected to the board. Figure 3-10: LVDS Connector Location Description Description GROUND GROUND LVDS_A_TX0-P LVDS_A_TX0-N LVDS_A_TX1-P LVDS_A_TX1-N LVDS_A_TX2-P LVDS_A_TX2-N LVDS_A_TXCLK-P LVDS_A_TXCLK-N LVDS_A_TX3-P LVDS_A_TX3-N GROUND GROUND LVDS_B_TX0-P LVDS_B_TX0-N...

  • Page 39: Lvds Backlight Connector

    NANO-QM770 EPIC SBC 3.2.9 LVDS Backlight Connector CN Label: INVERTER1 5-pin wafer, p=2.00mm CN Type: CN Location: See Figure 3-11 CN Pinouts: See Table 3-11 The backlight inverter connectors provide power to LCD panels. Figure 3-11: LVDS Backlight Inverter Connector Description BRIGHTNESS GROUND...

  • Page 40: Figure 3-12: Pcie Mini Card Slot Location

    NANO-QM770 EPIC SBC The PCIe Mini card slot enables a PCIe Mini card expansion module to be connected to the board. Cards supported include among others wireless LAN (WLAN) cards and IEI PCIe Mini disk on module (DOM) SSD cards. Figure 3-12: PCIe Mini Card Slot Location Description Description...

  • Page 41: Power Connector (12V)

    NANO-QM770 EPIC SBC Description Description 1.5V VCC3 Table 3-12: PCIe Mini Card Slot Pinouts 3.2.11 Power Connector (12V) CN Label: PWR1 CN Type: 4-pin connector, p=4.20mm CN Location: See Figure 3-13 CN Pinouts: See Table 3-13 The power connector is connected to an external power supply and supports 12V power input.

  • Page 42: Serial Port Connectors (Com1, Com2)

    NANO-QM770 EPIC SBC 3.2.12 RS-232 Serial Port Connectors (COM1, COM2) CN Label: COM1, COM2 10-pin header, p=2.00mm CN Type: CN Location: See Figure 3-14 CN Pinouts: See Table 3-14 The 10-pin serial port connectors provide two RS-232 serial communications channels. The COM serial port connectors can be connected to external RS-232 serial port devices.

  • Page 43: Sata Drive Connectors

    NANO-QM770 EPIC SBC CN Pinouts: See Table 3-15 This connector provides RS-422 or RS-485 communications. Figure 3-15: RS-422/485 Serial Port Connector Location Description RXD422- RXD422+ TXD422+/TXD485+ TXD422-/TXD485- Table 3-15: RS-422/485 Serial Port Connector Pinouts Use the optional RS-422/485 cable to connect to a serial device. The pinouts of the D-sub 9 connector are listed below.

  • Page 44: Sata Power Connectors

    NANO-QM770 EPIC SBC CN Location: See Figure 3-16 CN Pinouts: See Table 3-17 The SATA connectors connect to SATA hard drives or optical drives with data transfer speeds as high as 6Gb/s. Figure 3-16: SATA Drive Connector Locations Description Table 3-17: SATA Drive Connector Pinouts 3.2.15 SATA Power Connectors CN Label: CN1, CN2...

  • Page 45: Smbus Connector

    NANO-QM770 EPIC SBC Figure 3-17: SATA Power Connector Locations Description +V5S Table 3-18: SATA Power Connector Pinouts 3.2.16 SMBus Connector CN Label: CN Type: 4-pin wafer, p=1.25mm CN Location: See Figure 3-18 CN Pinouts: See Table 3-19 The SMBus (System Management Bus) connector provides low-speed system management communications.

  • Page 46: So-Dimm Connector

    NANO-QM770 EPIC SBC Description SMB_DATA SMB_CLK +V5S Table 3-19: SMBus Connector Pinouts 3.2.17 SO-DIMM Connector CN Label: DIMM1 204-pin DDR3 SO-DIMM connector CN Type: CN Location: See Figure 3-19 The SO-DIMM connector is for installing memory on the system. Figure 3-19: SO-DIMM Connector Location 3.2.18 SPI Flash Connector CN Label: JSPI1...

  • Page 47: Tpm Connector

    NANO-QM770 EPIC SBC Figure 3-20: SPI Flash Connector Location Description +V3.3M_SPI_CON SPI_CS SPI_SO_SW SPI_CLK_SW SPI_SI_SW Table 3-20: SPI Flash Connector Pinouts 3.2.19 TPM Connector CN Label: TPM1 CN Type: 20-pin header, p=2.54mm CN Location: See Figure 3-21 CN Pinouts: See Table 3-21 The Trusted Platform Module (TPM) connector secures the system on bootup.

  • Page 48: Usb 2.0 Connector

    NANO-QM770 EPIC SBC Figure 3-21: TPM Connector Location Description Description LCLK LFRAME# LRERST# LAD3 LAD2 LAD1 LAD0 SB3V SERIRQ GLKRUN# LPCPD# LDRQ# Table 3-21: TPM Connector Pinouts 3.2.20 USB 2.0 Connector CN Label: USB1 8-pin header, p=2.54mm CN Type: CN Location: See Figure 3-22 CN Pinouts: See Table 3-22...

  • Page 49: External Interface Connectors

    NANO-QM770 EPIC SBC Figure 3-22: USB Connector Location Description Description DATA- DATA+ DATA+ DATA- Table 3-22: USB Port Connector Pinouts 3.3 External Interface Connectors Figure 3-23 shows the NANO-QM770 motherboard external interface connectors. The NANO-QM770 on-board external interface connectors are shown in Figure 3-23. Figure 3-23: External Interface Connectors 3.3.1 DVI Connector CN Label:...

  • Page 50: Ethernet Connectors

    NANO-QM770 EPIC SBC CN Location: See Figure 3-23 CN Pinouts: See Table 3-23 and Figure 3-24 The 24-pin Digital Visual Interface (DVI) connector connects to high-speed, high-resolution digital displays. The DVI-I connector supports both digital and analog signals. Description Description Description TMDS Data2- TMDS Data1-...

  • Page 51: Hdmi Connectors

    NANO-QM770 EPIC SBC CN Pinouts: See Table 3-24 The LAN connector connects to a local network. DESCRIPTION DESCRIPTION MDIA3- MDIA2+ MDIA3+ MDIA1+ MDIA1- MDIA0- MDIA2- MDIA0+ Table 3-24: LAN Pinouts Figure 3-25: Ethernet Connector Description Description on: linked off: 10 Mb/s blinking: data is being sent/received green: 100 Mb/s orange: 1000 Mb/s...

  • Page 52: Usb 3.0 Connectors

    NANO-QM770 EPIC SBC Description Description HDMI_DATA2 HDMI_DATA2# HDMI_SCL HDMI_DATA1 HDMI_SDA HDMI_DATA1# HDMI_DATA0 HDMI_HPD HDMI_GND HDMI_DATA0# HDMI_GND HDMI_CLK HDMI_GND HDMI_GND HDMI_CLK# Table 3-26: HDMI Connector Pinouts Figure 3-26: HDMI Connector 3.3.4 USB 3.0 Connectors CN Label: USB_CON1, USB_CON2 USB 3.0 port CN Type: CN Location: See Figure 3-23...

  • Page 53: Table 3-27: Usb Port Pinouts

    NANO-QM770 EPIC SBC Description Description VBUS DATA1- DATA1+ SSRX1- SSRX1+ SSTX1- SSTX1+ VBUS DATA2- DATA2+ SSRX2- SSRX2+ SSTX2- SSTX2+ Table 3-27: USB Port Pinouts Page 39...

  • Page 54: Installation

    NANO-QM770 EPIC SBC Chapter Installation Page 40...

  • Page 55: Anti-Static Precautions

    NANO-QM770 EPIC SBC 4.1 Anti-static Precautions WARNING: Failure to take ESD precautions during installation may result in permanent damage to the product and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-QM770. Dry climates are especially susceptible to ESD. It is therefore critical to strictly adhere to the following anti-static precautions whenever the NANO-QM770, or any other electrical component, is handled.
  • Page 56 NANO-QM770 EPIC SBC WARNING: The installation instructions described in this manual should be carefully followed in order to prevent damage to the NANO-QM770, NANO-QM770 components and injury to the user. Before and during the installation please DO the following:  Read the user manual: The user manual provides a complete description of the installation instructions and configuration options.

  • Page 57: So-Dimm Installation

    NANO-QM770 EPIC SBC 4.3 SO-DIMM Installation To install an SO-DIMM, please follow the steps below and refer to Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket. Place the board on an anti-static mat. Step 2: Align the SO-DIMM with the socket. Align the notch on the memory with the notch on the memory socket.

  • Page 58: Jumper Settings

    NANO-QM770 EPIC SBC Figure 4-2: PCIe Mini Card Installation Step 1: Insert into the socket at an angle. Line up the notch on the card with the notch on the connector. Slide the PCIe Mini card into the socket at an angle of about 20º.

  • Page 59: At/Atx Mode Selection

    NANO-QM770 EPIC SBC Before the NANO-QM770 is installed in the system, the jumpers must be set in accordance with the desired configuration. The jumpers on the NANO-QM770 are listed in Table 4-1. Description Label Type AT/ATX mode selection J_ATXCTL1 3-pin header Clear CMOS J_CMOS1 3-pin header...

  • Page 60: Clear Cmos

    NANO-QM770 EPIC SBC Figure 4-3: AT/ATX Mode Selection Jumper Location 4.5.2 Clear CMOS Jumper Label: J_CMOS1 Jumper Type: 3-pin header, p=2.00mm Jumper Settings: See Table 4-3 See Figure 4-4 Jumper Location: If the NANO-QM770 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information.

  • Page 61: Clear Me Rtc Registers

    NANO-QM770 EPIC SBC Description Short 1-2 Keep CMOS Setup (Default) Short 2-3 Clear CMOS Setup Table 4-3: Clear CMOS Jumper Settings Figure 4-4: Clear CMOS Jumper Location 4.5.3 Clear ME RTC Registers Jumper Label: ME_RTC1 3-pin header, p=2.00mm Jumper Type: Jumper Settings: See Table 4-4 Jumper Location:...

  • Page 62: Flash Descriptor Security Override

    NANO-QM770 EPIC SBC Figure 4-5: Clear ME RTC Registers Jumper Location 4.5.4 Flash Descriptor Security Override Jumper Label: J_FLASH1 Jumper Type: 3-pin header, p=2.00mm Jumper Settings: See Table 4-5 Jumper Location: See Figure 4-6 The Flash Descriptor Security Override jumper specifies whether to override the flash descriptor.

  • Page 63: Lvds Voltage Selection

    NANO-QM770 EPIC SBC 4.5.5 LVDS Voltage Selection Jumper Label: J_VLVDS1 3-pin header, p=2.00mm Jumper Type: Jumper Settings: See Table 4-6 Jumper Location: See Figure 4-7 Selects the voltage of the LVDS connector. Description Short 1-2 +3.3 V (Default) Short 2-3 +5 V Table 4-6: LVDS Voltage Selection Jumper Settings Figure 4-7: LVDS Voltage Selection Jumper Location...

  • Page 64: Pcie Mini/Msata Mode Selection

    NANO-QM770 EPIC SBC Description 1024 X 768 (18bit) 1-2 & 3-4 1024 X 768 (24bit) Default 1280 X 800 (24bit) 1-2 & 5-6 1280 X 1024 (48bit) 3-4 & 5-6 1366 X 768 (24bit) 1-2 & 3-4 & 5-6 1440 X 900 (48bit) 1400 X 1050 (48bit) 1-2 &...

  • Page 65: Chassis Installation

    NANO-QM770 EPIC SBC Description Closed PCIe Mini (Default) Open mSATA Table 4-8: PCIe Mini/mSATA Mode Selection Jumper Settings Figure 4-9: PCIe Mini/mSATA Mode Selection Jumper Location 4.6 Chassis Installation 4.6.1 Airflow WARNING: Airflow is critical for keeping components within recommended operating termperatures.

  • Page 66: Internal Peripheral Device Connections

    NANO-QM770 EPIC SBC 4.7 Internal Peripheral Device Connections This section outlines the installation of peripheral devices to the onboard connectors. 4.7.1 AT Power Connection Follow the instructions below to connect the NANO-QM770 to an AT power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the NANO-QM770.

  • Page 67: Audio Kit Installation

    NANO-QM770 EPIC SBC Step 3: Connect Power Cable to Power Supply. Connect one of the 4-pin (1x4) Molex type power cable connectors to an AT power supply. See Figure 4-11. Figure 4-11: Connect Power Cable to Power Supply 4.7.2 Audio Kit Installation The Audio Kit that came with the NANO-QM770 connects to the audio connector on the NANO-QM770.

  • Page 68: Sata Drive Connection

    NANO-QM770 EPIC SBC Figure 4-12: Audio Kit Cable Connection Step 3: Connect the audio devices. Connect speakers to the line-out audio jack. Connect the output of an audio device to the line-in audio jack. Connect a microphone to the mic-in audio jack.Step 0: 4.7.3 SATA Drive Connection The NANO-QM770 is shipped with two SATA drive cable.

  • Page 69: Single Rs-232 Cable (W/O Bracket)

    NANO-QM770 EPIC SBC Figure 4-13: SATA Drive Cable Connection Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See Figure 4-13. Step 4: To remove the SATA cable from the SATA connector, press the clip on the connector at the end of the cable.

  • Page 70: Intel ® Amt Setup Procedure

    NANO-QM770 EPIC SBC Figure 4-14: Single RS-232 Cable Installation Step 3: Secure the bracket. The single RS-232 connector has two retention screws that must be secured to a chassis or bracket. Step 4: Connect the serial device. Once the single RS-232 connector is connected to a chassis or bracket, a serial communications device can be connected to the system.
  • Page 71 NANO-QM770 EPIC SBC process. Enter the Intel® current ME password as it requires (the Intel® default password is admin). NOTE: To change the password, enter a new password following the strong password rule (containing at least one upper case letter, one lower case letter, one digit and one special character, and be at least eight characters).

  • Page 72: Bios

    NANO-QM770 EPIC SBC Chapter BIOS Page 58...

  • Page 73: Introduction

    NANO-QM770 EPIC SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 74: Getting Help

    NANO-QM770 EPIC SBC Function Increase the numeric value or make changes Decrease the numeric value or make changes Page up Move to the next page Page down Move to the previous page Main Menu – Quit and do not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu General help, only for Status Page Setup Menu and Option...

  • Page 75: Main

    NANO-QM770 EPIC SBC  Security – Sets User and Supervisor Passwords.  Save & Exit – Selects exit options and loads default settings The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.

  • Page 76: Advanced

    NANO-QM770 EPIC SBC  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 77: Acpi Configuration

    NANO-QM770 EPIC SBC 5.3.1 ACPI Configuration The ACPI Configuration menu (BIOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced ACPI Settings Select ACPI sleep state the system will enter ACPI Sleep State [S1 only (CPU Stop C…] when the SUSPEND button...

  • Page 78: Rtc Wake Settings

    NANO-QM770 EPIC SBC 5.3.2 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event.

  • Page 79: Trusted Computing

    NANO-QM770 EPIC SBC  Enabled If selected, the following appears with values that can be selected: *Wake up every day *Wake up date *Wake up hour *Wake up minute *Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off.

  • Page 80: Cpu Configuration

    NANO-QM770 EPIC SBC  Security Device Support [Disable] Use the Security Device Support option to configure support for the TPM.  TPM support is disabled. Disable EFAULT  Enable TPM support is enabled. 5.3.4 CPU Configuration Use the CPU Configuration menu (BIOS Menu 6) to view detailed CPU specifications and configure the CPU.
  • Page 81 NANO-QM770 EPIC SBC  Max CPU Speed: Lists the maximum CPU processing speed.  Min CPU Speed: Lists the minimum CPU processing speed.  CPU Speed: Lists the CPU processing speed  Processor Core: Lists the number of the processor cores ...

  • Page 82: Sata Configuration

    NANO-QM770 EPIC SBC 5.3.5 SATA Configuration Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced SATA Mode Selection [AHCI] Determines how SATA controller(s) operate.

  • Page 83: Intel(R) Rapid Start Technology

    NANO-QM770 EPIC SBC 5.3.6 Intel(R) Rapid Start Technology Use the Intel(R) Rapid Start Technology menu to configure Intel® Rapid Start Technology support. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Intel(R) Rapid Start Technology [Disabled] --------------------- : Select Screen ...

  • Page 84: Amt Configuration

    NANO-QM770 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Intel Trusted Execution Technology Configuration Intel TXT support only can be enabled/disabled if SMX is enabled. VT and VT-d support must also be enabled prior --------------------- : Select Screen to TXT.

  • Page 85: Usb Configuration

    NANO-QM770 EPIC SBC  Intel AMT [Enabled] Use Intel AMT option to enable or disable the Intel® AMT function.  Intel® AMT is disabled Disabled  Enabled Intel® AMT is enabled EFAULT  Unconfigure ME [Disabled] Use the Unconfigure ME option to perform ME unconfigure without password operation. ...

  • Page 86: F81866 Super Io Configuration

    NANO-QM770 EPIC SBC  USB Devices The USB Devices Enabled field lists the USB devices that are enabled on the system  Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support.

  • Page 87: Serial Port N Configuration

    NANO-QM770 EPIC SBC 5.3.10.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 13) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Serial Port 1 Configuration Enable or Disable Serial Port (COM) Serial Port [Enabled]...
  • Page 88 NANO-QM770 EPIC SBC  IO=3F8h; Serial Port I/O port address is 3E8h and the interrupt IRQ=3, 4 address is IRQ3, 4  Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3, 4 IRQ=3, 4  IO=3E8h;...
  • Page 89 NANO-QM770 EPIC SBC  IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt IRQ=3, 4 address is IRQ3, 4 5.3.10.1.3 Serial Port 3 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. ...

  • Page 90: F81866 H/W Monitor

    NANO-QM770 EPIC SBC 5.3.11 F81866 H/W Monitor The F8186 H/W Monitor menu (BIOS Menu 14) shows the operating temperature, fan speeds and system voltages. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced PC Health Status Smart Fan Mode Select CPU temperature :+62 C Accuracy: 1.

  • Page 91: Smart Fan Mode Configuration

    NANO-QM770 EPIC SBC VSB5V VCC3V VSB3V VBAT 5.3.11.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 15) to configure the smart fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Smart Fan Mode Configuration Smart Fan Mode Select...

  • Page 92: Serial Port Console Redirection

    NANO-QM770 EPIC SBC  SYS_FAN1 Smart Fan Control [Auto Duty-Cycle Mode] Use the SYS_FAN1 Smart Fan Control option to configure the System Smart Fan (SYS_FAN1).  Manual Duty The fan spins at the speed set in Manual by Duty Mode Cycle settings ...

  • Page 93: Iei Feature

    NANO-QM770 EPIC SBC  Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function.  Disabled the console redirection function Disabled EFAULT  Enabled Enabled the console redirection function 5.3.13 IEI Feature Use the IEI Feature menu (BIOS Menu 17) to configure One Key Recovery function. Aptio Setup Utility –...

  • Page 94: Chipset

    NANO-QM770 EPIC SBC 5.4 Chipset Use the Chipset menu (BIOS Menu 18) to access the Hostbridge and Southbridge configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction. Aptio Setup Utility –...

  • Page 95: Pch-Io Configuration

    NANO-QM770 EPIC SBC 5.4.1 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 19) to configure the PCH chipset. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Chipset PCH-IO Configuration Control Detection of the Azalia device. Intel PCH RC Version 1.1.0.0 Disabled = Azalia will be Intel PCH SKU Name...

  • Page 96: System Agent (Sa) Configuration

    NANO-QM770 EPIC SBC  Disabled Disable internal HDMI codec for High Definition Audio  Enable internal HDMI codec for High Definition Audio Enabled EFAULT  Restore AC Power Loss [Last State] Use the Restore AC Power Loss BIOS option to specify what state the system returns to if there is a sudden loss of power to the system.

  • Page 97: Graphics Configuration

    NANO-QM770 EPIC SBC Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset System Agent Bridge Name IvyBridge Enabled to reduce power System Agent RC Version 1.1.0.0 consumption in system VT-d Capability Supported off state. VT-d [Enabled] > Graphics Configuration --------------------- : Select Screen >...

  • Page 98: Bios Menu 21: Graphics Configuration

    NANO-QM770 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Chipset Graphics Configuration Select which of IGFX VBIOS Version 2132 IGFX/PEG/PCI Graphics Igfx Frequency 350 MHz device should be Primary Display Or select SG for Primary Display [IGFX] Switchable Gfx.
  • Page 99 NANO-QM770 EPIC SBC then only be used as graphics memory, and is no longer available to applications or the operating system. Configuration options are listed below:     128M Default  256M  512M  1024M  DVMT Total Gfx Mem [MAX] Use the DVMT Total Gfx Mem option to select DVMT5.0 total graphic memory size used by the internal graphic device.

  • Page 100: Memory Configuration

    NANO-QM770 EPIC SBC  800x600 18BIT  1024x768 18BIT  1024x768 24BIT  1280x800 24BIT  1280x1024 48BIT  1366x768 24BIT  1440x900 48BIT  1400x1050 48BIT  1600x900 48BIT  1600x1200 48BIT  1680x1050 48BIT  1920x1080 48BIT  1920x1200 48BIT ...

  • Page 101: Boot

    NANO-QM770 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Chipset Memory Information Memory RC Version 1.1.0.0 Memory Frequency 1333 MHz Total Memory 2048 MB (DDR3) DIMM#0 2048 MB (DDR3) CAS Latency (tCL) --------------------- : Select Screen Minimum delay time ...
  • Page 102 NANO-QM770 EPIC SBC  Bootup NumLock State [On] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up.  Allows the Number Lock on the keyboard to be EFAULT enabled automatically when the computer system boots up.
  • Page 103 NANO-QM770 EPIC SBC  Option ROM Messages [Force BIOS] Use the Option ROM Messages option to set the Option ROM display mode.  Sets display mode to force BIOS. Force EFAULT BIOS  Sets display mode to current. Keep Current ...

  • Page 104: Security

    NANO-QM770 EPIC SBC 5.6 Security Use the Security menu (BIOS Menu 24) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set, then this only limits access to Setup and is...

  • Page 105: Bios Menu 25:Exit

    NANO-QM770 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults Restore User Defaults --------------------- : Select Screen...

  • Page 106: Software Drivers

    NANO-QM770 EPIC SBC Chapter Software Drivers Page 92...

  • Page 107: Available Software Drivers

    NANO-QM770 EPIC SBC 6.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates. The following drivers can be installed on the system: ...

  • Page 108: Figure 6-1: Introduction Screen

    NANO-QM770 EPIC SBC Figure 6-1: Introduction Screen Step 3: Click NANO-QM770. Step 4: A new screen with a list of available drivers appears (Figure 6-2). Figure 6-2: Available Drivers Step 5: Install all of the necessary drivers in this menu. S t e p 0 : Page 94...

  • Page 109: Chipset Driver Installation

    NANO-QM770 EPIC SBC 6.3 Chipset Driver Installation To install the chipset driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “Chipset”. Step 3: Locate the setup file and double click on it. Step 4: The Welcome Screen in Figure 6-3 appears.

  • Page 110: Figure 6-4: Chipset Driver License Agreement

    NANO-QM770 EPIC SBC Figure 6-4: Chipset Driver License Agreement Step 9: The Read Me file in Figure 6-5 appears. Step 10: Click Next to continue. Figure 6-5: Chipset Driver Read Me File Page 96...

  • Page 111: Figure 6-6: Chipset Driver Setup Operations

    NANO-QM770 EPIC SBC Step 11: Setup Operations are performed as shown in Figure 6-6. Step 12: Once the Setup Operations are complete, click Next to continue. Figure 6-6: Chipset Driver Setup Operations Step 13: The Finish screen in Figure 6-7 appears. Step 14: Select “Yes, I want to restart this computer now”...

  • Page 112: Graphics Driver Installation

    NANO-QM770 EPIC SBC Figure 6-7: Chipset Driver Installation Finish Screen 6.4 Graphics Driver Installation To install the Graphics driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “Graphics” and select the folder which corresponds to the operating system.

  • Page 113: Figure 6-8: Graphics Driver Welcome Screen

    NANO-QM770 EPIC SBC Figure 6-8: Graphics Driver Welcome Screen Step 6: The License Agreement in Figure 6-9 appears. Step 7: Click Yes to accept the agreement and continue. Figure 6-9: Graphics Driver License Agreement Step 8: Setup Operations are performed as shown in Figure 6-10. Page 99...

  • Page 114: Figure 6-10: Graphics Driver Setup Operations

    NANO-QM770 EPIC SBC Step 9: Once the Setup Operations are complete, click Next to continue. Figure 6-10: Graphics Driver Setup Operations Step 10: The Finish screen in Figure 6-11 appears. Step 11: Select “Yes, I want to restart this computer now” and click Finish.Step 0: Figure 6-11: Graphics Driver Installation Finish Screen Page 100...

  • Page 115: Lan Driver Installation

    NANO-QM770 EPIC SBC 6.5 LAN Driver Installation Step 1: Right-click the Computer button from the start menu and select Properties. (Figure 6-12). Figure 6-12: Windows Control Panel Step 2: The system control panel window in Figure 6-13 appears. Step 3: Click the Device Manager link (Figure 6-13).

  • Page 116: Figure 6-14: Device Manager List

    NANO-QM770 EPIC SBC Step 4: A list of system hardware devices appears (Figure 6-14). Step 5: Right-click the Ethernet Controller that has question marks next to it (this means Windows does not recognize the device). Step 6: Select Update Driver Software. Figure 6-14: Device Manager List Step 7: The Update Driver Software Window appears (Figure 6-15).

  • Page 117: Figure 6-15: Update Driver Software Window

    NANO-QM770 EPIC SBC Figure 6-15: Update Driver Software Window Step 8: Select “Browse my computer for driver software” and click N to continue. Step 9: Click Browse to select “X:\3-LAN” directory in the Locate File window, where “X:\” is the system CD drive. (Figure 6-16). Figure 6-16: Locate Driver Files Step 10: Click N...

  • Page 118: Audio Driver Installation

    NANO-QM770 EPIC SBC Figure 6-17: LAN Driver Installation Step 12: The Finish screen in Figure 6-18 appears. Click Close to exit. Step 0: Figure 6-18: LAN Driver Installation Complete 6.6 Audio Driver Installation To install the audio driver, please do the following. Step 1: Access the driver list.

  • Page 119: Figure 6-19: Installshield Wizard Welcome Screen

    NANO-QM770 EPIC SBC Step 2: Click “Audio” and select the folder which corresponds to the operating system. Step 3: Double click the setup file. Step 4: The InstallShield Wizard is prepared to guide the user through the rest of the process.

  • Page 120: Figure 6-20: Audio Driver Software Configuration

    NANO-QM770 EPIC SBC Figure 6-20: Audio Driver Software Configuration Step 8: After the driver installation process is complete, a confirmation screen appears (Figure 6-21). Figure 6-21: Restart the Computer Page 106...

  • Page 121: Intel® Rapid Storage Technology Driver Installation

    NANO-QM770 EPIC SBC Step 9: The confirmation screen offers the option of restarting the computer now or later. For the settings to take effect, the computer must be restarted. Click F INISH restart the computer. Step 0: 6.7 Intel® Rapid Storage Technology Driver Installation To install the Intel®...

  • Page 122: Figure 6-23: Sata Raid Driver License Agreement

    NANO-QM770 EPIC SBC Figure 6-23: SATA RAID Driver License Agreement Step 9: The Read Me file in Figure 6-24 appears. Step 10: Click Next to continue. Figure 6-24: SATA RAID Driver Read Me File Step 11: Setup Operations are performed as shown in Figure 6-25. Step 12: Once the Setup Operations are complete, click Next to continue.

  • Page 123: Figure 6-25: Sata Raid Driver Setup Operations

    NANO-QM770 EPIC SBC Figure 6-25: SATA RAID Driver Setup Operations Step 13: The Finish screen in Figure 6-26 appears. Step 14: Select “Yes, I want to restart this computer now” and click Finish.Step 0: Figure 6-26: SATA RAID Driver Installation Finish Screen Page 109...

  • Page 124: Usb 3.0 Driver Installation

    NANO-QM770 EPIC SBC 6.8 USB 3.0 Driver Installation WARNING: Do not run this driver’s installer (Setup.exe) from a USB storage device (ie. external USB hard drive or USB thumb drive). For proper installation, please copy driver files to a local hard drive folder and run from there.

  • Page 125: Figure 6-28: Usb 3.0 Driver License Agreement

    NANO-QM770 EPIC SBC Step 7: Read the License Agreement. Step 8: Click Yes to continue. Figure 6-28: USB 3.0 Driver License Agreement Step 9: The Read Me file in Figure 6-29 appears. Step 10: Click Next to continue. Figure 6-29: USB 3.0 Driver Read Me File Page 111...

  • Page 126: Figure 6-30: Usb 3.0 Driver Setup Operations

    NANO-QM770 EPIC SBC Step 11: Setup Operations are performed as shown in Figure 6-30. Step 12: Once the Setup Operations are complete, click Next to continue. Figure 6-30: USB 3.0 Driver Setup Operations Step 13: The Finish screen in Figure 6-31 appears. Step 14: Select “Yes, I want to restart this computer now”...

  • Page 127: Intel® Amt Driver Installation

    NANO-QM770 EPIC SBC 6.9 Intel® AMT Driver Installation The package of the Intel® AMT components includes  Intel® Management Engine Interface (Intel® ME Interface)  Intel® Dynamic Application Loader  Intel® Identity Protection Technology (Intel® IPT)  Serial Over LAN (SOL) ...

  • Page 128: Figure 6-32: Intel® Me Driver Welcome Screen

    NANO-QM770 EPIC SBC Figure 6-32: Intel® ME Driver Welcome Screen Step 6: The license agreement in Figure 6-33 appears. Step 7: Read the License Agreement. Step 8: Click Yes to continue. Figure 6-33: Intel® ME Driver License Agreement Step 9: Setup Operations are performed as shown in Figure 6-34.

  • Page 129: Figure 6-34: Intel® Me Driver Setup Operations

    NANO-QM770 EPIC SBC Figure 6-34: Intel® ME Driver Setup Operations Step 11: The Finish screen in Figure 6-35 appears. Step 12: Select “Yes, I want to restart this computer now” and click Finish.Step 0: Figure 6-35: Intel® ME Driver Installation Finish Screen Page 115...

  • Page 130: A Regulatory Compliance

    NANO-QM770 EPIC SBC Appendix Regulatory Compliance Page 116...
  • Page 131 NANO-QM770 EPIC SBC DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 132: Bbios Options

    NANO-QM770 EPIC SBC Appendix BIOS Options Page 118...
  • Page 133 NANO-QM770 EPIC SBC Below is a list of BIOS configuration options in the BIOS chapter. 　 BIOS Information .........................61 　 System Date [xx/xx/xx] ......................62 　 System Time [xx:xx:xx] .......................62 　 ACPI Sleep State [S1 only (CPU Stop Clock)]..............63 　 Wake System with Fixed Time [Disabled] .................64 　...
  • Page 134 NANO-QM770 EPIC SBC 　 PEG0 – Gen X [Gen1]......................84 　 DVMT Pre-Allocated [128MB]....................84 　 DVMT Total Gfx Mem [MAX]....................85 　 Primary IGFX Boot Display [VBIOS Default] ..............85 　 LCD Panel Type [By Hardware] ..................85 　 Backlight Control [Inverted]....................86 　 Bootup NumLock State [On]....................88 　...

  • Page 135: C Terminology

    NANO-QM770 EPIC SBC Appendix Terminology Page 121...
  • Page 136 NANO-QM770 EPIC SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 137 NANO-QM770 EPIC SBC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module. The digital inputs and digital outputs are general control signals that control the on/off circuit of external devices or TTL devices.
  • Page 138 NANO-QM770 EPIC SBC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 139: D Digital I/O Interface

    NANO-QM770 EPIC SBC Appendix Digital I/O Interface Page 125...

  • Page 140: Introduction

    NANO-QM770 EPIC SBC D.1 Introduction The DIO connector on the NANO-QM770 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 141: Assembly Language Sample 1

    NANO-QM770 EPIC SBC D.2 Assembly Language Sample 1 AX, 6F08H ;setting the digital port as input AL low byte = value AH – 6FH Sub-function: AL – 9 :Set the digital port as OUTPUT :Digital I/O input value D.3 Assembly Language Sample 2 AX, 6F09H ;setting the digital port as output BL, 09H...

  • Page 142: E Hazardous Materials Disclosure

    NANO-QM770 EPIC SBC Appendix Hazardous Materials Disclosure Page 128...

  • Page 143: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    NANO-QM770 EPIC SBC E.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 144 NANO-QM770 EPIC SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated (Pb) (Hg) (Cd) Chromium Biphenyls Diphenyl (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply Assemblies Battery This toxic or hazardous substance is contained in all of the homogeneous materials for the part is...
  • Page 145 NANO-QM770 EPIC SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。 Page 131...

This manual is also suitable for:

Nano-qm770

Table of Contents
