EPIC SBC with AMD Geode
Dual COM, Mini PCI Slot, CF, USB 2.0 and Audio
Quick Installation Guide
Package Contents
NANO-LX2 package includes the following items:
1 x NANO-LX2 Single Board Computer
1 x IDE flat cable 44p/44p
1 x Audio cable
1 x Dual ports USB cable
1 x Mini jumper pack
1 x Utility CD
1 x QIG (Quick Installation Guide)
NANO-LX2
Version 1.0
Mar. 14, 2008
©2006 Copyright by IEI Technology corp.
All rights reserved.
TM
LX800 CPU, VGA, Dual LAN,
1
Advertisement
Table of Contents
Related Manuals for IEI Technology NANO-LX2
Summary of Contents for IEI Technology NANO-LX2
- Page 1 NANO-LX2 Quick Installation Guide Version 1.0 Mar. 14, 2008 Package Contents NANO-LX2 package includes the following items: 1 x NANO-LX2 Single Board Computer 1 x IDE flat cable 44p/44p 1 x Audio cable 1 x Dual ports USB cable 1 x Mini jumper pack...
- Page 2 Specifications CPU: On board AMD Geode LX800 (500MHz) Processor System Chipset: AMD Geode LX800 + AMD Geode CS5536 BIOS: AWARD BIOS System memory: 1 x 200-pin DDR 333/400MHz SO-DIMM socket support up to 1G Ethernet: Dual 10/100Mbps Realtek RTL8100C Ethernet chipset I/O Interface: 2 x RS-232 1 x IDE...
- Page 3 Operation: 5% ~ 95% non-condensing Dimension: 115mm x 165mm; Weight: GW: 820g; NW 200g Ordering Information NANO-LX2-800-R10 EPIC SBC with AMD Geode LX800 CPU, VGA, Dual LAN, Dual COM, Mini PCI Slot, CF, USB 2.0 and Audio NANO-LX2-CE050 ® Windows CE 5.0 &...
- Page 4 Jumpers setting & Connector CN1 : AT Power select jumper DESCRIPTION Open Use ATX Power Short Use AT Power if use ATX Power will be auto power on JP8 : Compact Flash Master/Slave Function DESCRIPTION Master Slave CN2: ATX power button connector DESCRIPTION PWRBTN# JP2: Reset button connector...
- Page 5 AUDIO2: Audio connector DESCRIPTION DESCRIPTION LINE_OUT-R LINE_IN-R LINE_OUT-L LINE_IN-L MIC-IN1 MIC-IN2 LED1 : POWER & HD LED DESCRIPTION DESCRIPTION HD_LED# 1&2 HDD LED 3&4 POWER LED DIO1: GPIO connector DESCRIPTION DESCRIPTION GPO0 GPO1 GPO2 GPO3 GPI0 GPI1 GPI2 GPI3 COM1 : COM PORT DB9 connector DESCRIPTION DESCRIPTION DCD#...
- Page 6 CN9 : IDE 44pin 2.0mm connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# IOW# IOR# ACK# CABLEID CS0# CS1# ASP# USB2: USB Connector DESCRIPTION DESCRIPTION BT1 : BATTARY DESCRIPTION +3.3V...
- Page 7 PWR1 : POWER input connector DESCRIPTION Layout...
- Page 8 Dimension...
