Input Channels 1–16
PHANTOM switch
GAIN control
PAD switch
AD converter
Phase
Input swap
Input flip
Input select switch
Attenuator
EQ
Dynamics
Delay
ON/OFF
Fader
AUX, EFFECT send
Solo
Pan
Routing
Metering
+48 V, CH 1-6, CH 7-12
44 dB (–60 to –16 dB), CH 1–12 detented
30 dB (–20 to +10 dB); CH 13/14, 15/16
0/26 dB attenuation CH 1–12
20-bit linear 128-times oversampling
Normal/Reverse
Normal (CH 1–8)/Swap (OPTION INPUT CH 17–24)
Normal (CH 13/14)/Flip (DIGITAL STEREO IN)
CH 15/16–2TR IN
0 to –96 dB (1 dB steps)
4-band PEQ (Low, Lo-Mid, Hi-Mid, High)
Compressor, Gate, Ducking, Expander, Compander
0–250 ms, fs=44.1 kHz
60 mm motorized
INPUT, AUX 1, AUX 2, AUX 3, AUX 4, EFFECT 1, EFFECT 2
AUX 1–4, EFFECT 1, EFFECT 2 (pre/post fader)
ON/OFF
AFL/PFL
33 positions (L1–16, CENTER, R1–16)
STEREO, BUS 1–4
Direct out (OMNI OUT 1–4, OPTION OUT via OUTPUT SELECT)
Displayed on LCD
Peak hold ON/OFF
Input Channels 1–16
