Security Cover
For certain applications you may wish to fit a protective cover over the 01V's GAIN con-
trols and PAD switches. Although Yamaha do not make such a cover, the 01V has four
fixing holes to affix a custom-made cover. If you fit such a cover, make sure that the fix-
ing screws do not protrude inside the 01V by more than 10 mm. The fixing holes accept
M3-size machine screws, and are spaced 40.0 mm vertically, 414 mm horizontally.
Rack-mounting Kit
The 01V can be rack mounted using the optional RK124 Rack Mount Kit. See your
Yamaha dealer for details.
Attach the rack-mount brackets as shown below.
259
Security Cover
01V—Owner's Manual
