SMART Board 6075S Installation And Maintenance Manual page 28

Chapter 2
Installing the display
NOTES
Refer to the display's specifications for power requirements and power consumption
o
information (see More information on page 18).
The AC power output on the back of the display is rated at 250 W.
o
To turn on and set up the display for the first time
IMPORTANT
Install the OPS PC module before you turn the display on.
NOTE
If a USB drive is connected to the display's service port, do not remove the USB drive. The USB drive
contains an important firmware update.
1. Flick the switch beside the AC power inlet to the ON (I) position.
2. Press the Power button
3. Select your preferred language, and then tap Next.
4. Select your country, and then tap Next.
5. Select your time zone, and then tap Next.
6. Set the date, and then tap Next.
7. Set the time, and then tap Next.
8. Name the display, and then tap Next.
smarttech.com/kb/171414
on the front control panel or remote control
28
