DT-4500 Series C- and Ku-Band Down Converters
Specifications

2.2.7.2 Return Loss

20 dB minimum with I/O Module

2.2.7.3 Impedance

50Ω

2.2.7.4 Noise Figure

11 dB Maximum @ 0 dB Attenuation
2.2.8

IF Output

2.2.8.1 Level

+20 dBm @ 1 dB Compression

2.2.8.2 Range

Contact Comtech EF Data Product Support for your specific requirements.
• STANDARD:
• OPTIONAL:

2.2.8.3 Non-carrier Spurious

-80 dBm

2.2.8.4 Carrier Spurious

-65 dBc @ 0 dBm output
50 to 88 MHz or 104 to 176 MHz
50 to 80 MHz or 100 to 180 MHz
