DT-4500 Series C- and Ku-Band Down Converters
Front and Rear Panel Connectors

4.2.4.1 Removable Module Connectors

The module connector types vary depending on the operating band and
impedance of the purchased unit:
• The IF Input/Output and LP (Loop) In/Out connectors are typically female
BNC connectors.
• The RF Input/Output and LP (Loop) In/Out connectors may be female
Type 'N' or female Type 'SMA' connectors, depending on the application.
• All switch modules feature a 'J3 | HSB' (High Speed Bus) connector.
Table 4-6 provides the pinout specifications for this D-Sub 25-pin female
(DB-25F) connector. The mating connector is a DB-25M connector.

Table 4-6. 'J3 | HSB' Data Interface Pinout

Pin # Description
1
2
3
4
5
6
7
8 +14V Out
9
10
11
12
13
14
15
16
17
18
19
20 +14V Out
21
22
23
24
25
4–17
MN/DT4500.IOM
Cntl_12
Cntl_10
Cntl_8
Cntl_6
Cntl_4
Cntl_2
Cntl_In
+14V In
Aux_3
Aux_1
-Rx/Tx
GND
Cntl_11
Cntl_9
Cntl_7
Cntl_5
Cntl_3
Cntl_1
+14V In
GND
Aux_2
GND
+Rx/Tx
Revision 2
