DT-4500 Series C- and Ku-Band Down Converters
Specifications
Impedance
CEFD P/N
(Ohms)
AS/0101-31 75
AS/0101-32 50
AS/0101-33 75
AS/0101-34 50
AS/0101-41 50

2.1.8.5.5 RSM (Receive Switch Module) Assemblies

Impedance
CEFD P/N
(Ohms)
AS/0101-4 75
AS/0101-6 75
AS/0101-7 50
AS/0101-16 50
AS/0101-20 75
AS/0101-26 50
AS/0101-37 50
AS/0101-38 75

2.2 Operational Specifications

2.2.1

Available Models / Operating Frequency Ranges

Contact Comtech EF Data Product Support for your specific requirements.

2.2.1.1 C-Band Units

• DT-4503: 3625 to 4200 MHz
• DT-4503/C: 3400 to 4200 MHz
• DT-4503/D: 3400 to 3700 MHz
• DT-4503/E: 4500 to 4800 MHz

2.2.1.2 Ku-Band Units

• DT-4510: 10.95 to 11.70 GHz
Comments
DT-4513, UT-4514/F w/Isolator, Type 'SMA'
DT-4513, UT-4514/F w/Isolator, Type 'SMA
DT-4513, UT-4518/F w/Isolator, Type 'SMA'
DT-4513, UT-4518/F w/Isolator, Typr 'SMA'
DT-4513 1:1 Switching
Comments
DT-4503 Switching, Down, Type 'SMA'
DT-4503, DT-4572, UT-4579 Switching, Type 'N'
DT-4503, DT-4572, UT-4579 Switching, Type 'N'
DT-4503 I/O, Type 'SMA'
Receive Switch, RSM2
RSM2, Type 'N'
DT-451X w/Isolator, Type 'SMA'
DT-451X w/Isolator, Type 'SMA'
