Note
You should refer to the table above and the label attached to the power and I/O cable to wire the
device.

3.2 Indicator

The device has five indicators, including PWR, LNK, ACK, U1 and U2 indicators. Read following
sections to get the indicator status of the device.
● PWR indicator: It is the power indicator, and it is solid blue when the device operates normally.
● LNK indictor: It is the network connection indicator, and it is solid green when the network
transmission is normal.
● ACK indictor: It is the network transmission indicator, and it is flashing yellow when the network
transmission is normal. The flashing speed is related with data transmission speed.
● U1 indicator: It is user indicator 1. The indicator is solid red after the device creates Profinet
communication.
● U2 indicator: It is user indicator 2. The indicator is slow flashing blue after the device is powered
on.
Status
Solid
Unlit
Fast flashing
Slow flashing
Very slow flashing
SC5000 Series Smart Camera Quick Start Guide
Table 3-2 Indicator Status Definition
The indicator is in solid all the time.
The indicator is unlit all the time.
Flashing interval: 200 to 300 ms
Flashing interval: 1000 ms
Flashing interval: 2000 ms
Description
5
