Parameter Name
Output Logic Level Low
Output Logic Level High
Output Falling Delay
Output Rising Delay
Output Falling Time
Output Rising Time

7.3 Input Signal Wiring

The device can receive external input signal via I/O interface.
Note
● Here we take type II device as an example to introduce input signal wiring.
● Input signal wiring may differ by external device types.
PNP Device
NPN Device
If the VCC of NPN device is 12 VDC or 24 VDC and pull-up resistor is not used, its wiring is as
follows.
SC5000 Series Smart Camera Quick Start Guide
Table 7-2 Output Electrical Feature
VL
VH
TDF
TDR
TF
TR
PWR
Device Power
Opto-Isolated
Input
Input Signal Ground
Device Power Ground
Figure 7-5 Input Signal Connecting to PNP Device
Parameter Symbol
VCC
GND of PWR
17
Value
730 mV
3.2 VDC
6.3 μs
68 μs
3 μs
60 μs
PNP Device Power
Signal Line
●
PNP Power Ground
GND of VCC
PNP
Device
