No. Name
1 Lens Cap
2 Screw Hole
3 Light Source
Gigabit Ethernet
4
Interface
12-Pin M12
5
Interface
6 PWR Indicator
7 LNK Indicator
8 ACT Indicator
9 U1/U2 Indicator
SC5000 Series Smart Camera Quick Start Guide
Table 2-1 Component Description
It can be replaced with other lens cap.
It is used to fix the device to the installation position. It is recommended
to use supplied M4 screws.
It refers to LED lamps providing light.
Note
● The default color of LED lamps is white. Red, blue and NIR are optional.
● The type II device does not have own light source, and you can use an
external light source instead.
It refers to gigabit Ethernet interface for transmitting data. The interface
is designed with screw threads to tighten connection between the device
and cable, and thus avoiding influence caused by vibration.
It provides power, input/output, and serial port signal. The interface is
designed with screw threads to tighten connection between the device
and cable, and thus avoiding influence caused by vibration.
It is the power indicator. The indicator is solid blue when the device
operates normally.
It is network connection indicator. The indicator is solid green when the
network transmission is normal.
It is network transmission indicator. The indicator is flashing yellow when
the network transmission is normal. The flashing speed is related with
data transmission speed.
The device has 2 user indicators, U1 and U2. They are used to indicate
whether some functions of the device are normal or not.
Description
3
