Operation Flow - HikRobot SC5000 Series Quick Start Manual

No. Name
3 Tool Display Area
4 Live View Window
5 Other Areas

6.2 Operation Flow

Note
● Refer to the user manual of the SCMVS client software for detailed parameter settings and
operations.
● Click More on the upper right corner of the client software, and click User Manual to open it.
You can follow the overall operation flow below to operate the device via the client software.
SC5000 Series Smart Camera Quick Start Guide
This area displays operation results of vision tools loaded in projects in real
time. You can click
This area displays images and results under camera mode and image mode
in real time. Under image mode, you can import images into the device.
You can switch languages, view the user manual and client version
information here.
I/O Settings
Figure 6-2 Operation Flow
Description
to view specific operation results.
Log into Client
Software
Create/Edit
Project
Parameters
Settings
Base Image
Settings
Tool Settings
Output Settings
Run Project
Camera
Monitoring
14
Communication
Settings
