6-3 TRANSMIT ADJUSTMENT (continued)
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC's keyboard, and then push the [ENTER] key.
ADJUSTMENT
ADJUSTMENT
CONDITION
1
ANALOG
DEVIATION
2
-Preparation-
3 • Channel: 1-21
-Adjust-
• Transmitting
(Wide)
4 • Channel: 1-22
(Middle)**
[Wide Band Width]
: "Middle"
(see the page 6-5)
• Transmitting
5 • Channel:
(Narrow)
1-23 [L]
1-22 [H], [350 MHz]
• Transmitting
1
CTCSS/DTCS
DEVIATION
-Preparation-
2 • Channel:
-Adjust-
1-24 [L]
(Wide)
1-23 [H], [350 MHz]
• Transmitting
3 • Channel:
(Narrow)
1-25 [L]
1-24 [H], [350 MHz]
• Transmitting
**: For only [EUR], [DPM] versions. [L]= Low band, [H]=High band, [350 MHz]=350 MHz band.
6-4 RECEIVE ADJUSTMENT
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC's keyboard, and then push the [ENTER] key.
ADJUSTMENT
ADJUSTMENT
CONDITION
1
RECEIVE
SENSITIVITY
2
-Preparation-
3 • Channel:
-Adjustment-
1-26 [L]
(Band center)
1-25 [H], [350 MHz]
• Receiving
4 • Channel:
-Adjustment-
1-27 [L]
(Band low)
1-26 [350 MHz]
For only [L]
• Receiving
and [350 MHz]
5 • Channel:
-Adjustment-
1-28 [L]
(Band high)
1-26 [H]
1-27 [350 MHz]
• Receiving
[L]= Low band, [H]=High band, [350 MHz]=350 MHz band.
†
: The output level of the standard signal generator (SSG) is indicated as the SSG's open circuit.
(Replacement page)
OPERATION
Set the item [TX Mode] to "1."
–
1) Connect the modulation analyzer to the TX
antenna connector, through an attenuator,
and then set to:
HPF:
LPF:
De-emphasis: OFF
–
Detector:
2) Connect an audio generator to the MIC line,
through the JIG cable, and then set to:
Modulation:
Level:
Waveform:
1) Adjust the deviation using [←] / [→] keys of
the PC's keyboard.
2) Push the [ENTER] key to store the adjust
value.
Set the item [TX Mode] to "3."
–
1) Adjust the deviation using [←] / [→] keys of
the PC's keyboard.
2) Push the [ENTER] key to store the adjust
value.
OPERATION
Set the item [RX Mode] to "1."
–
Connect the SSG to the RX antenna connec-
tor, and then set to:
†
Level :
–
Modulation:
Deviation:
1) Set the SSG to:
Frequency:
2) Select the item [BPF C ALL], and then
push the [ENTER] key.
1) Set the SSG to:
Frequency:
2) Select the item [BPF L ALL], and then
push the [ENTER] key.
1) Set the SSG to:
Frequency:
2) Select the item [BPF H ALL], and then
push the [ENTER] key.
The underlined parts have been updated from
the previous version of the addendum.
OFF
20 kHz
(P-P)/2
1015 Hz
40 mV rms
Sine wave
+20 dBμ (–87 dBm)
1 kHz
±3.5 kHz
435.000 MHz [L]
450.100 MHz [H]
375.000 MHz [350 MHz]
400.100 MHz [L]
350.100 MHz [350 MHz]
469.900 MHz [L]
519.900 MHz [H]
399.900 MHz [350 MHz]
6-9
ADJUSTMENT
VALUE
ITEM/POINT
"1"
[TX Mode]
–
±4.10 ±0.05 kHz
[MOD (Wide)]
±3.20 ±0.05 kHz
[MOD (Middle)]
±2.10 ±0.05 kHz
[MOD (Narrow)]
"3"
[TX Mode]
±0.70 ±0.02 kHz
[CTCSS (Wide)]
[CTCSS
±0.35 ±0.02 kHz
(Narrow)]
ADJUSTMENT
VALUE
ITEM/POINT
"1"
[RX Mode]
–
[BPF C ALL]
(Automatic
[BPF L ALL]
adjustment)
[BPF H ALL]
–
–
