Icom IC-FR6000 Service Manual Addendum page 34

August 2016
[MAIN-D UNIT]
REF PART
DESCRIPTION
NO. NO.
C614 4030017730 S.CER C1005 JB 1H 471K-T
C615 4030017370 S.CER C1005 CH 1H 3R5B-T
C616 4030017460 S.CER C1005 JB 1H 102K-T
C617 4030017420 S.CER C1005 CH 1H 470J-T
C618 4030017420 S.CER C1005 CH 1H 470J-T
C619 4030017420 S.CER C1005 CH 1H 470J-T
C620 4030017420 S.CER C1005 CH 1H 470J-T
C621 4030017420 S.CER C1005 CH 1H 470J-T
C622 4030019560 S.CER GRM21BB31C106KE15L
C623 4030019990 S.CER C1005 JB 1C 104K-T
C624 4030019990 S.CER C1005 JB 1C 104K-T
C625 4030017460 S.CER C1005 JB 1H 102K-T
C626 4510009810 S.ELE EEEFK1E220R
C637 4510009680 S.ELE EEEFK1E471P
C638 4030019120 S.CER GRM188B31E105KA75D
C645 4030016930 S.CER C1005 JB 1A 104K-T
C652 4030016930 S.CER C1005 JB 1A 104K-T
C653 4030019560 S.CER GRM21BB31C106KE15L
C656 4030016930 S.CER C1005 JB 1A 104K-T
C657 4030019560 S.CER GRM21BB31C106KE15L
C658 4030016930 S.CER C1005 JB 1A 104K-T
C659 4030019560 S.CER GRM21BB31C106KE15L
C660 4030016930 S.CER C1005 JB 1A 104K-T
C661 4030019560 S.CER GRM21BB31C106KE15L
C662 4030017490 S.CER C1608 JB 1A 105K-T
C663 4030017490 S.CER C1608 JB 1A 105K-T
C664 4030017490 S.CER C1608 JB 1A 105K-T
C665 4030017490 S.CER C1608 JB 1A 105K-T
C666 4550006250 S.TAN TEESVA 1A 106M8R
Eqv. 4550007520 S.TAN F931A106MAABMA
C667 4550006250 S.TAN TEESVA 1A 106M8R
Eqv. 4550007520 S.TAN F931A106MAABMA
C668 4550006250 S.TAN TEESVA 1A 106M8R
Eqv. 4550007520 S.TAN F931A106MAABMA
C669 4550006250 S.TAN TEESVA 1A 106M8R
Eqv. 4550007520 S.TAN F931A106MAABMA
C670 4030016930 S.CER C1005 JB 1A 104K-T
C700 4030018900 S.CER C1005 JB 0J 474K-T
C701 4030018900 S.CER C1005 JB 0J 474K-T
C702 4030016930 S.CER C1005 JB 1A 104K-T
C703 4030017460 S.CER C1005 JB 1H 102K-T
C704 4030017460 S.CER C1005 JB 1H 102K-T
C705 4030017460 S.CER C1005 JB 1H 102K-T
C706 4030016930 S.CER C1005 JB 1A 104K-T
C707 4030016930 S.CER C1005 JB 1A 104K-T
C709 4030019460 S.CER C1608 JB 0J 106M-T
C710 4030016930 S.CER C1005 JB 1A 104K-T
C711 4030017460 S.CER C1005 JB 1H 102K-T
C712 4030016930 S.CER C1005 JB 1A 104K-T
C713 4030019630 S.CER GRM31C2C1H104JA01L
C714 4030019630 S.CER GRM31C2C1H104JA01L
C715 4030019630 S.CER GRM31C2C1H104JA01L
C716 4030019630 S.CER GRM31C2C1H104JA01L
C717 4030019630 S.CER GRM31C2C1H104JA01L
C719 4030016930 S.CER C1005 JB 1A 104K-T
C720 4030016930 S.CER C1005 JB 1A 104K-T
C721 4030017420 S.CER C1005 CH 1H 470J-T
C722 4030016930 S.CER C1005 JB 1A 104K-T
C723 4030017460 S.CER C1005 JB 1H 102K-T
C725 4030018900 S.CER C1005 JB 0J 474K-T
C726 4030018900 S.CER C1005 JB 0J 474K-T
C727 4030016930 S.CER C1005 JB 1A 104K-T
C728 4030017460 S.CER C1005 JB 1H 102K-T
C729 4030017460 S.CER C1005 JB 1H 102K-T
C730 4030017460 S.CER C1005 JB 1H 102K-T
C731 4030019990 S.CER C1005 JB 1C 104K-T
C732 4030019990 S.CER C1005 JB 1C 104K-T
C734 4030019460 S.CER C1608 JB 0J 106M-T
C735 4030016930 S.CER C1005 JB 1A 104K-T
C736 4030017460 S.CER C1005 JB 1H 102K-T
C737 4030016930 S.CER C1005 JB 1A 104K-T
C738 4030016930 S.CER C1005 JB 1A 104K-T
C739 4030019630 S.CER GRM31C2C1H104JA01L
C740 4030019630 S.CER GRM31C2C1H104JA01L
C741 4030019630 S.CER GRM31C2C1H104JA01L
C742 4030019630 S.CER GRM31C2C1H104JA01L
C743 4030019630 S.CER GRM31C2C1H104JA01L
C746 4030017420 S.CER C1005 CH 1H 470J-T
C747 4030016930 S.CER C1005 JB 1A 104K-T
C748 4030020000 S.CER C1005 JB 1A 105K-T
C749 4030017460 S.CER C1005 JB 1H 102K-T
C752 4030017400 S.CER C1005 CH 1H 220J-T
C753 4030017400 S.CER C1005 CH 1H 220J-T
C755 4030017640 S.CER C1005 CH 1H 150J-T
C760 4030009910 S.CER C1608 CH 1H 040B-T
C761 4030009520 S.CER C1608 CH 1H 020B-T
C762 4030006990 S.CER C1608 CH 1H 080D-T
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[MAIN-D UNIT]
H/V REF PART
M.
LOCATION NO. NO.
B 29.0/13.2 J1 6510026770 S.CON AXK540147YG
B 63.2/117.5 J2 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M)
T 93.8/64.6 J4 6510023512 S.CON 28FLT-SM2-TB(LF)(SN)(M)
B 134.1/43.7 J5 6510023110 CON
T 64.9/53.3 J6 6450002470 CON
T 77.9/109.3 J8 6510023092 S.CON 20FLT-SM2-TB(LF)(SN)(M)
T 74.2/96.8 J9 6510019371 S.CON B3B-ZR-SM4-TF(LF)(SN)
T 31.5/2.8 J10 6510004910 CON
T 64.5/73.4 J11 6510004910 CON
B 126.8/16.0 J12 6510025970 S.CON 41-002AA-R
B 126.3/20.3
B 126.8/17.2
B 129.4/23.2 DS1 5040002961 S.LED SML-A12MT T86J
B 84.9/23.4 DS2 5040002961 S.LED SML-A12MT T86J
T 13.0/133.5 DS3 5040003001 S.LED SML-A12UT T86J
T 57.2/46.7
B 33.9/59.0
B 31.9/59.9 MF1 2710000870 FAN
B 34.8/62.1
T 35.6/64.8
B 36.8/63.4 W1 7030014230 JUM
B 30.1/62.3 W2 7030014230 JUM
B 38.9/63.3 W4 8920000830 C_C
B 43.2/62.7
T 75.0/15.6
T 69.9/15.6 EP1 6910016330 S.BEA MMZ1005S 601CT-S
T 74.4/24.2 EP2 6910015370 S.BEA ACZ1005Y-102-T
T 69.9/24.2 EP3 6910015370 S.BEA ACZ1005Y-102-T
T 76.7/15.3 EP4 6910016330 S.BEA MMZ1005S 601CT-S
EP5 6910016330 S.BEA MMZ1005S 601CT-S
T 71.6/15.2 EP6 6910015370 S.BEA ACZ1005Y-102-T
EP7 6910016330 S.BEA MMZ1005S 601CT-S
T 76.1/25.0 EP8 6910015370 S.BEA ACZ1005Y-102-T
EP9 6910016330 S.BEA MMZ1005S 601CT-S
T 71.6/25.0 EP10 6910011560 BEA
EP13 6910011330 TER
B 44.2/34.2 EP14 6910011330 TER
T 124.9/44.5 EP16 6910023420 S.BEA MMZ1005A222ET
T 124.9/45.4 EP17 6910021240 S.BEA MMZ1005A152ET
B 122.8/46.0 EP18 6910021240 S.BEA MMZ1005A152ET
T 121.2/42.5 EP19 6910018460 S.BEA MMZ1005Y102C-T
T 119.2/40.6 EP20 6910018460 S.BEA MMZ1005Y102C-T
T 121.6/44.6 EP21 6910018460 S.BEA MMZ1005Y102C-T
B 121.9/47.7 EP22 6910018460 S.BEA MMZ1005Y102C-T
B 121.0/47.7 EP23 6910018460 S.BEA MMZ1005Y102C-T
B 119.9/48.2 EP24 6910018460 S.BEA MMZ1005Y102C-T
B 118.4/47.1 EP25 6910018460 S.BEA MMZ1005Y102C-T
B 118.4/46.2 EP26 6910018460 S.BEA MMZ1005Y102C-T
T 115.9/44.4 EP27 6910018460 S.BEA MMZ1005Y102C-T
B 83.9/45.9 EP28 6910018460 S.BEA MMZ1005Y102C-T
B 83.9/41.6 EP29 6910018460 S.BEA MMZ1005Y102C-T
B 83.9/43.8 EP30 6910018460 S.BEA MMZ1005Y102C-T
T 83.9/46.0 EP31 6910018460 S.BEA MMZ1005Y102C-T
T 83.9/43.8 EP32 6910018460 S.BEA MMZ1005Y102C-T
B 117.4/39.5 EP33 6910018460 S.BEA MMZ1005Y102C-T
B 116.3/62.0 EP34 6910018460 S.BEA MMZ1005Y102C-T
B 113.4/57.3 EP35 6910021770 S.BEA MMZ1005F560CT
B 114.2/63.7 EP37 6910021770 S.BEA MMZ1005F560CT
B 117.3/57.9 EP38 6910021770 S.BEA MMZ1005F560CT
T 35.3/78.8
T 32.8/78.4
B 35.4/80.1
T 34.2/81.4
T 33.0/79.7
T 33.3/81.4
B 37.0/80.5
B 36.6/81.4
B 37.4/82.5
B 36.6/84.2
B 35.7/84.2
T 31.7/84.5
T 32.2/85.4
B 28.5/104.1
T 28.5/102.5
T 28.5/100.4
B 28.5/99.9
B 28.5/102.0
B 29.2/88.2
B 20.6/88.3
B 26.5/122.3
B 28.0/118.2
B 16.9/37.5
B 43.1/60.4
B 46.5/35.6
T 27.4/138.0
T 31.0/140.0
T 25.3/142.2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
19
DESCRIPTION M.
T
T
T
3008L-8P8C
JY-3510A1-130
T
T
NR-DS-E 01
NR-DS-E 01
T
B
B
B
AFB0512HB-7X22 HK
RJ20S0OHM
RJ20S0OHM
CAB-1116
B
T
T
B
B
B
B
B
T
HF70BB4.5X5X1.6
OT-009 M3
OT-009 M3
B
B
B
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
B
B
B
H/V
LOCATION
23.1/63.7
15.1/15.6
70.9/102.1
58.9/15.7
94.7/14.3
58.7/44.6
96.0/1.1
126.0/1.1
111.0/1.1
134.1/46.4
120.4/39.9
35.5/80.1
28.7/62.0
41.3/73.9
39.5/109.0
40.7/36.7
96.2/48.8
48.9/39.4
44.8/60.4
134.6/45.1
36.2/70.2
66.1/106.8
62.8/98.7
62.8/99.6
73.6/104.7
72.4/105.0
71.5/105.0
70.4/105.0
72.9/99.0
68.2/99.1
67.3/99.1
65.8/99.1
74.7/99.0
70.5/99.5
64.1/105.0
65.1/105.0
66.1/105.0
17.8/37.5
44.0/47.8
46.4/36.5
