Icom IC-FR6000 Service Manual Addendum page 14

August 2016
[MAIN-C UNIT]
REF PART
NO. NO.
J1* 6510026770 AXK540147YG
J2* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J4* 6510023512 28FLT-SM2-TB (LF) (SN) (M)
J5 6510023110 3008L-8P8C
J6 6450002470 JY-3510A 01-130
J8* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J9* 6510019371 B3B-ZR-SM4-TF (LF) (SN)
J10 6510004910 NR-DS-E 01
J11 6510004910 NR-DS-E 01
J12* 6510025970 41-002AA-R
MF1 2710000870 AFB0512HB-7X22 HK
W1 7030014230 RJ20S0OHM
W2 7030014230 RJ20S0OHM
W4 8920000830 CAB-1116
W5 8900020500 OPC-2249
8900020500 OPC-2249
EP10 6910011560 HF70BB4.5X5X1.6
EP13 6910011330 OT-009 M3
EP14 6910011330 OT-009 M3
MP1 8510018070 2979 VCO CASE
MP2 8510018060 2979 VCO COVER
MP3 8510018070 2979 VCO CASE
MP4 8510018060 2979 VCO COVER
MP5 8210024440 3063 SUB M-PANEL
MP6 8310070880 3063 S-LED PLATE
8310070880 3063 S-LED PLATE
8310070880 3063 S-LED PLATE
8310070880 3063 S-LED PLATE
8310070880 3063 S-LED PLATE
8310083910 3063 S-LED PLATE (B)
8310083910 3063 S-LED PLATE (B)
8310083910 3063 S-LED PLATE (B)
8310083910 3063 S-LED PLATE (B)
MP7 8930073920 3063 SP COVER
MP8 8010020981 3063 CHASSIS-1
MP9 8110009360 3063 SU-COVER
MP10 8110009370 3063 SL-COVER
MP11 8930074300 3063 PC PLATE
8930074300 3063 PC PLATE
8930074300 3063 PC PLATE
8930074300 3063 PC PLATE
8930074300 3063 PC PLATE
8930074300 3063 PC PLATE
8930074300 3063 PC PLATE
8930085080 3063 IF PLATE
8930085080 3063 IF PLATE
MP12 8930074180 O-RING (BR) (TOP)
MP13 8930075020 3063 B-PACKING (TOP)
MP14 8930075030 3063 C-PACKING (TOP)
MP15 8930073930 3063 SP RUBBER (TOP)
MP16 8930058990 SHIELD SPONGE (V)
MP17 8930062160 HIMELON SHEET (CL)
MP18 8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930079651 2979 D-SUB PLATE (A)-1
8930079651 2979 D-SUB PLATE (A)-1
8930070921 2979 D-SUB PLATE-1
8930079651 2979 D-SUB PLATE (A)-1
8930079651 2979 D-SUB PLATE (A)-1
MP19 8930058990 SHIELD SPONGE (V)
MP20 8510015660 2681 F-SHIELD PLATE
MP21 8930048550 2177 CLIP
MP22 8810008451 BIND M4 X 8 ZK3
MP23 8930075080 HR25F DUST CAP
MP24 8810009611 FLAT M2.6X 6 ZK3
MP25 8810009611 FLAT M2.6X 6 ZK3
MP26 8810010780 PH BT M3 X20 NI-ZK3
MP27 8810008661 PHBT M3 X 8 NI-ZC3
MP28 8810008661 PHBT M3 X 8 NI-ZC3
MP29 8810008661 PHBT M3 X 8 NI-ZC3
MP30 8810008661 PHBT M3 X 8 NI-ZC3
MP31 8810008661 PHBT M3 X 8 NI-ZC3
MP32 8810008661 PHBT M3 X 8 NI-ZC3
MP33 8510018780 3063 ANT CASE
MP35 8810003361 SET SCREWC M3 X 6 ZC3
MP36 8930066040 SPONGE (IK)
8930066040 SPONGE (IK)
8930066040 SPONGE (IK)
8930066040 SPONGE (IK)
MP37 8510018790 3063 VCO SHIELD
MP38 8510018820 3063 SHIELD PLATE
*: Refer to "BOARD LAYOUTS."
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Amended page)
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
[#37] 1
[#82] 1
2
1
1
1
1
1
1
1
[#07] 1
[#14] 1
[#15] 1
[#16] 1
[#23] 1
[#35] 1
[#36] 1
[#37] 1
[#82] 1
1
1
1
1
[#07] 1
[#14] 1
[#15] 1
[#16] 1
[#23] 1
[#35] 1
[#36] 1
[#37] 1
[#82] 1
1
1
1
1
1
1
[#07] 1
[#14] 1
[#15] 1
[#16] 1
[#23] 1
[#35] 1
[#36] 1
[#37] 1
[#82] 1
1
1
1
4
1
8
9
4
19
2
1
2
3
4
2
2
[#23] 1
[#35] 1
[#37] 1
[#82] 1
1
1
[MAIN-D UNIT]
REF PART
NO. NO.
J1* 6510026770 AXK540147YG
J2* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J4* 6510023512 28FLT-SM2-TB (LF) (SN) (M)
J5 6510023110 3008L-8P8C
J6 6450002470 JY-3510A 01-130
J8* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J9* 6510019371 B3B-ZR-SM4-TF (LF) (SN)
J10 6510004910 NR-DS-E 01
J11 6510004910 NR-DS-E 01
J12* 6510025970 41-002AA-R
MF1 2710000870 AFB0512HB-7X22 HK
W1 7030014230 RJ20S0OHM
W2 7030014230 RJ20S0OHM
W4 8920000830 CAB-1116
EP10 6910011560 HF70BB4.5X5X1.6
EP13 6910011330 OT-009 M3
EP14 6910011330 OT-009 M3
MP1 8510018070 2979 VCO CASE
MP2 8510018060 2979 VCO COVER
MP3 8510018070 2979 VCO CASE
MP4 8510018060 2979 VCO COVER
MP5 8210024440 3063 SUB M-PANEL
MP6 8310070880 3063 S-LED PLATE
MP7 8930073920 3063 SP COVER
MP8 8010020981 3063 CHASSIS-1
MP9 8110009360 3063 SU-COVER
MP10 8110009370 3063 SL-COVER
MP11 8930074300 3063 PC PLATE
MP12 8930074180 O-RING (BR) (TOP)
MP13 8930075020 3063 B-PACKING (TOP)
MP14 8930075030 3063 C-PACKING (TOP)
MP15 8930073930 3063 SP RUBBER (TOP)
MP16 8930058990 SHIELD SPONGE (V)
MP17 8930062160 HIMELON SHEET (CL)
MP18 8930070921 2979 D-SUB PLATE-1
MP19 8930058990 SHIELD SPONGE (V)
MP20 8510015660 2681 F-SHIELD PLATE
MP21 8930048550 2177 CLIP
MP22 8810008451 BIND M4 X 8 ZK3
MP23 8930075080 HR25F DUST CAP
MP24 8810009611 FLAT M2.6X 6 ZK3
MP25 8810009611 FLAT M2.6X 6 ZK3
MP26 8810010780 PH BT M3 X20 NI-ZK3
MP27 8810008661 PHBT M3 X 8 NI-ZC3
MP28 8810008661 PHBT M3 X 8 NI-ZC3
MP29 8810008661 PHBT M3 X 8 NI-ZC3
MP30 8810008661 PHBT M3 X 8 NI-ZC3
MP31 8810008661 PHBT M3 X 8 NI-ZC3
MP32 8810008661 PHBT M3 X 8 NI-ZC3
MP33 8510018780 3063 ANT CASE
MP35 8810003361 SET SCREWC M3 X 6 ZC3
MP37 8510018790 3063 VCO SHIELD
MP38 8510018820 3063 SHIELD PLATE
MP41 8930058990 SHIELD SPONGE (V)
8-2
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
8
9
4
19
2
1
2
3
4
2
2
1
1
1
