Icom IC-FR6000 Service Manual Addendum page 58

Jul. 2012
SECTION 8
[CHASSIS PARTS]
REF ORDER
NO. NO.
MP1 8810003361 SET SCREWC M3 X 6 ZC3
MP2 8810003361 SET SCREWC M3 X 6 ZC3
MP3 8110009330 3063 U-COVER
MP4 8110009340 3063 BOTTOM COVER D
MP5 8930073980 3063 ANGLE
MP6 8930073990 3063 CENTER ANGLE
MP7 8810005771 BIND M3 X 8 ZK3BLACK
MP9 8810009061 FLAT M3 X 6 ZK3
MP10 8810008661 PHBT M3 X 8 NI-ZC3
MP11 8810003361 SET SCREWC M3 X 6 ZC3
[MAIN UNIT]
(For all models except the IC-FR6000-L)
REF ORDER
NO. NO.
J1* 6510026770 AXK540147YG
J2* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J4* 6510023512 28FLT-SM2-TB (LF) (SN) (M)
J5 6510023110 3008L-8P8C <KIN>
J6 6450000140 HSJ0807-01-010
J8* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J9* 6510019371 B3B-ZR-SM4-TF (LF) (SN)
J10 6510004910 NR-DS-E 01 <SSC>
J11 6510004910 NR-DS-E 01 <SSC>
MF1 2710000870 AFB0512HB-7X22 <USE>HK
W1 7030012290 RDS2T0R0
W2 7030012290 RDS2T0R0
W4 8900017520 OPC-1783
EP10 6910011560 HF70BB4.5X5X1.6
EP13 6910011330 OT-009 M3
EP14 6910011330 OT-009 M3
MP1 8510018070 2979 VCO CASE Y1005
MP2 8510018060 2979 VCO COVER Y1006
MP3 8510018070 2979 VCO CASE Y1005
MP4 8510018060 2979 VCO COVER Y1006
MP5 8210024440 3063 SUB M-PANEL
MP6 8310070880 3063 S-LED PLATE
MP7 8930073920 3063 SP COVER
MP8 8010020980 3063 CHASSIS
MP9 8110009360 3063 SU-COVER
MP10 8110009370 3063 SL-COVER
MP11 8930074300 3063 PC PLATE
MP12 8930074180 O-RING (BR) (TOP)
MP13 8930075020 3063 B-PACKING (TOP)
MP14 8930075030 3063 C-PACKING (TOP)
MP15 8930073930 3063 SP RUBBER (TOP)
MP16 8930058990 SHIELD SPONGE (V)
MP17 8930062160 HIMELON SHEET (CL)
MP18 8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930070921 2979 D-SUB PLATE-1
8930079651 2979 D-SUB PLATE (A)-1 Y2142A
8930079651 2979 D-SUB PLATE (A)-1 Y2142A
8930070921 2979 D-SUB PLATE-1
MP19 8930058990 SHIELD SPONGE (V)
MP20 8510015660 2681 F-SHIELD PLATE
MP21 8930048550 2177 CLIP
MP22 8810008451 BIND M4 X 8 ZK3
MP23 8930075080 HR25F DUST CAP <LIA>
MP24 8810009611 FLAT M2.6X 6 ZK3
MP25 8810009611 FLAT M2.6X 6 ZK3
MP26 8810010780 PH BT M3 X20 NI-ZK3
MP27 8810008661 PHBT M3 X 8 NI-ZC3
MP28 8810008661 PHBT M3 X 8 NI-ZC3
MP29 8810008661 PHBT M3 X 8 NI-ZC3
MP30 8810008661 PHBT M3 X 8 NI-ZC3
MP31 8810008661 PHBT M3 X 8 NI-ZC3
MP32 8810008661 PHBT M3 X 8 NI-ZC3
MP33 8510018780 3063 ANT CASE Y1076
MP35 8810003361 SET SCREWC M3 X 6 ZC3
MP36 8930066040 SPONGE (IK)
8930066040 SPONGE (IK)
MP37 8510018790 3063 VCO SHIELD Y1078
MP38 8510018820 3063 SHIELD PLATE Y1085
*: Refer to "BOARD LAYOUTS."
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Replacement page)
MECHANICAL PARTS
DESCRIPTION QTY.
4
1
R Y2146 1
1
2
1
11
7
2
[DPM-01] only 6
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Y2143A [USA-01] 1
Y2143A [EXP-01] 1
Y2143A [CHN-02] 1
Y2143A [USA-02] 1
Y2143A [EXP-02] 1
[EUR-01] 1
[DPM-01] 1
Y2143A [DPM-03] 1
1
1
1
4
1
8
9
4
19
2
1
2
3
4
2
2
[EUR-01] 1
[DPM-01] 1
1
1
[FRONT UNIT]
REF ORDER
NO. NO.
J501* 6510019121 S8B-PH-SM4-TB (LF) (SN)
J502* 6510019121 S8B-PH-SM4-TB (LF) (SN)
J503 6450002210 3017-8821 <KIN>
J504* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
DS500 5030002811 L4-0013TVY-2 <TES>
DS501 5040002710 EMPG3338S
DS502 5040002720 EMVR3338S
DS503 5040002710 EMPG3338S
DS504 5040002720 EMVR3338S
DS511 5040002150 VRPG3349S-734
DS512 5040002150 VRPG3349S-734
S506 2250000511 RH70N1037E20-13F-2781
SP501 2510001221 C052SB500-14 <OSC>
W501 8900011801 OPC-1199A <KN>
W502 8900017540 OPC-1785
EP501 8930065150 SRCN-2781-SP-N-W (SHJ)
EP503 6910019600 LM-5
EP504 6910019610 LM-7 (SPACER)
MP501 8930064260 2781 LCD HOLDER Y753
MP502 8210021190 2781 REFLECTOR
MP503 8610012160 KNOB N324
MP504 8610012150 KNOB N325
MP507 8930064220 2781 KNOB RUBBER (TOP)S
MP508 8930075200 HIMELON SHEET (CY)
MP510 8930059000 2601 SP NET
MP511 8210025550 3063 FRONT PANEL (A)
MP512 8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
MP513 8310070870 3063 WINDOW PLATE
MP514 8210024431 3063 M-PANEL-1
MP515 8930074000 3063 SP ANGLE
MP516 8110009350 3063 FRONT COVER Y2145
MP517 8930073820 3063 FRONT KEY <SEP>
MP518 8930073911 3063 M-COVER-1
MP519 8930074020 3063 KNOB RUBBER (TOP)
MP520 8930075010 3063 A-PACKING (TOP)
MP529 8810008661 PHBT M3 X 8 NI-ZC3
MP530 8810008661 PHBT M3 X 8 NI-ZC3
MP531 8810008661 PHBT M3 X 8 NI-ZC3
MP532 8810008661 PHBT M3 X 8 NI-ZC3
MP533 8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
[CONNECT UNIT]
REF ORDER
NO. NO.
J601* 6510027920 IMSA-9631S-28Y934
J602 6510023210 CD6125SA1J0 <CVI>
S1* 2260003070 MINISMDC150F/24-2 <UDX>
W601 8900017500 OPC-1852 (P0.5N28L90)
8 - 1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
4
1
1
1
1
1
2
1
1
[USA-01] 1
[EXP-01] 1
[CHN-02] 1
[CHN-01] 1
[EXP-03] 1
[USA-02] 1
[EXP-02] 1
[EUR-01] 1
[DPM-01] 1
[DPM-03] 1
[DPM-02] 1
1
1
1
1
1
1
1
1
6
2
4
6
[USA-01] 5
[EXP-01] 5
[CHN-02] 5
[CHN-01] 5
[EXP-03] 5
[USA-02] 5
[EXP-02] 5
[EUR-01] 5
[DPM-01] 5
[DPM-03] 5
[DPM-02] 5
DESCRIPTION QTY.
1
1
1
1
