August 2016
6-6 TRANSMIT ADJUSTMENT (continued)
(For [#63], [#64], [#65], [#66], [#67], [#68], [#69], [#75], [#76], and [#77])
1) Select an adjustment item using cursor or [↑] / [↓] keys of the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [←] / [→] keys of the PC's keyboard, and then push the [ENTER] key.
ADJUSTMENT
ADJUSTMENT
CONDITION
1
DIGITAL
DEVIATION
2
-Preparation-
3 • Channel: 1-13
-Adjust-
• Transmitting
(Band 1)
4 • Channel: 1-14
(Band 2)
• Transmitting
5 • Channel: 1-15
(Band 3)
• Transmitting
6 • Channel: 1-16
(Band 4)
• Transmitting
7 • Channel: 1-17
(Band 5)
• Transmitting
8 • Channel: 1-18
(Band 6)
• Transmitting
9 • Channel: 1-19
(Band 7)
• Transmitting
10 • Channel: 1-20
(Band 8)
• Transmitting
1
ANALOG
DEVIATION
2
-Preparation-
3 • Channel: 1-21
-Adjust-
• Transmitting
(Wide)
4 • Channel: 1-22
(Middle)**
[Wide Band Width]
: "Middle"
(see the page 6-5)
• Transmitting
5 • Channel:
(Narrow)
1-23 [L]
1-22 [H], [350 MHz]
• Transmitting
1
CTCSS/DTCS
DEVIATION
-Preparation-
2 • Channel:
-Adjust-
1-24 [L]
(Wide)
1-23 [H], [350 MHz]
• Transmitting
3 • Channel:
(Narrow)
1-25 [L]
1-24 [H], [350 MHz]
• Transmitting
**: For only [EUR], [DPM] versions. [L]= Low band, [H]=High band, [350 MHz]=350 MHz band.
(Amended page)
OPERATION
• Set the item [TX Mode] to "16."
1) Connect the modulation analyzer to
the TX antenna connector through the
attenuator.
2) Set the modulation analyzer set to:
HPF:
LPF:
De-emphasis: OFF
Detector:
1) Adjust the deviation using [←] / [→] keys
of the PC's keyboard.
2) Push the [ENTER] key to store the adjust
value.
Set the item [TX Mode] to "1."
1) Connect the modulation analyzer to
the TX antenna connector, through an
attenuator, and then set to:
HPF:
LPF:
De-emphasis: OFF
Detector:
2) Connect an audio generator to the MIC line,
through the JIG cable, and then set to:
Modulation:
Level:
Waveform:
1) Adjust the deviation using [←] / [→] keys
of the PC's keyboard.
2) Push the [ENTER] key to store the adjust
value.
Set the item [TX Mode] to "3."
1) Adjust the deviation using [←] / [→] keys
of the PC's keyboard.
2) Push the [ENTER] key to store the adjust
value.
OFF
20 kHz
(P-P)/2
OFF
20 kHz
(P-P)/2
1015 Hz
40 mV rms
Sine wave
6-12
ADJUSTMENT
VALUE
ITEM/POINT
"16"
[TX Mode]
[MOD (Digital)]
[MOD Slant
Band 0]
[MOD Slant
Band 1]
[MOD Slant
Band 2]
±1.37 ±0.02 kHz
[MOD Offset
(High)]
[MOD Slant
Band 3]
[MOD Slant
Band 4]
[MOD Slant
Band 5]
"1"
[TX Mode]
±4.10 ±0.05 kHz
[MOD (Wide)]
±3.20 ±0.05 kHz
[MOD (Middle)]
±2.10 ±0.05 kHz
[MOD (Narrow)]
"3"
[TX Mode]
±0.70 ±0.02 kHz
[CTCSS (Wide)]
[CTCSS
±0.35 ±0.02 kHz
(Narrow)]
