Icom IC-FR6000 Service Manual Addendum page 15

August 2016
[MAIN-E UNIT]
REF PART
NO. NO.
J1* 6510026770 AXK540147YG
J2* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J4* 6510023512 28FLT-SM2-TB (LF) (SN) (M)
J5 6510023110 3008L-8P8C
J6 6450002470 JY-3510A 01-130
J8* 6510023092 20FLT-SM2-TB (LF) (SN) (M)
J9* 6510019371 B3B-ZR-SM4-TF (LF) (SN)
J10 6510004910 NR-DS-E 01
J11 6510004910 NR-DS-E 01
J12* 6510025970 41-002AA-R
MF1 2710000870 AFB0512HB-7X22 HK
W1 7030014230 RJ20S0OHM
W2 7030014230 RJ20S0OHM
W4 8920000830 CAB-1116
EP10 6910011560 HF70BB4.5X5X1.6
EP13 6910011330 OT-009 M3
EP14 6910011330 OT-009 M3
MP1 8510018070 2979 VCO CASE
MP2 8510018060 2979 VCO COVER
MP3 8510018070 2979 VCO CASE
MP4 8510018060 2979 VCO COVER
MP5 8210024440 3063 SUB M-PANEL
MP6 8310070880 3063 S-LED PLATE
MP7 8930073920 3063 SP COVER
MP8 8010020981 3063 CHASSIS-1
MP9 8110009360 3063 SU-COVER
MP10 8110009370 3063 SL-COVER
MP11 8930074300 3063 PC PLATE
MP12 8930074180 O-RING (BR) (TOP)
MP13 8930075020 3063 B-PACKING (TOP)
MP14 8930075030 3063 C-PACKING (TOP)
MP15 8930073930 3063 SP RUBBER (TOP)
MP16 8930058990 SHIELD SPONGE (V)
MP17 8930062160 HIMELON SHEET (CL)
MP18 8930079651 2979 D-SUB PLATE (A)-1
MP19 8930058990 SHIELD SPONGE (V)
MP20 8510015660 2681 F-SHIELD PLATE
MP21 8930048550 2177 CLIP
MP22 8810008451 BIND M4 X 8 ZK3
MP23 8930075080 HR25F DUST CAP
MP24 8810009611 FLAT M2.6X 6 ZK3
MP25 8810009611 FLAT M2.6X 6 ZK3
MP26 8810010780 PH BT M3 X20 NI-ZK3
MP27 8810008661 PHBT M3 X 8 NI-ZC3
MP28 8810008661 PHBT M3 X 8 NI-ZC3
MP29 8810008661 PHBT M3 X 8 NI-ZC3
MP30 8810008661 PHBT M3 X 8 NI-ZC3
MP31 8810008661 PHBT M3 X 8 NI-ZC3
MP32 8810008661 PHBT M3 X 8 NI-ZC3
MP33 8510018780 3063 ANT CASE
MP35 8810003361 SET SCREWC M3 X 6 ZC3
MP36 8930066040 SPONGE (IK)
MP37 8510018790 3063 VCO SHIELD
MP38 8510018820 3063 SHIELD PLATE
[FAN UNIT]
REF PART
NO. NO.
J1 6510011441 B4P-VH (LF) (SN)
J2 6510009371 B4B-ZR (LF) (SN)
J3 6510009371 B4B-ZR (LF) (SN)
MP1 8930073170 SPONGE (JQ)
*: Refer to "BOARD LAYOUTS."
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Amended page)
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
8
9
4
19
2
1
2
3
4
2
2
1
1
1
DESCRIPTION QTY.
1
1
1
1
[ACCESSORIES]
REF PART
NO. NO.
W1 8900017530 OPC-1784 M2K
W2 8900017530 OPC-1784 M2K
W3 8900021150 OPC-2243
W4 8920001160 CAB-1149
8920001160 CAB-1149
MP1 8930075520 3063 HANDLE
MP4 8310071490 3063 KEY SEAL
8-3
DESCRIPTION QTY.
1
Only [#82] 1
Only [#82] 1
[#07] 1
[#09] 1
1
1
