Icom IC-FR6000 Service Manual Addendum page 17

August 2016
[FRONT UNIT]
REF PART
DESCRIPTION
NO. NO.
C544 4550006250 S.TAN TEESVA 1A 106M8R
Eqv. 4550007520 S.TAN F931A106MAABMA
C545 4030017420 S.CER C1005 CH 1H 470J-T
C546 4030017420 S.CER C1005 CH 1H 470J-T
C547 4030017420 S.CER C1005 CH 1H 470J-T
C548 4030017460 S.CER C1005 JB 1H 102K-T
C549 4030017460 S.CER C1005 JB 1H 102K-T
C551 4030017420 S.CER C1005 CH 1H 470J-T
C553 4030017420 S.CER C1005 CH 1H 470J-T
C555 4030018860 S.CER C1005 JB 0J 105K-T
C556 4030016790 S.CER C1005 JB 1E 103K-T
C558 4550006480 S.TAN TEESVA 1C 475M8R
Eqv. 4550007260 S.TAN F931C475MAABMA
C559 4030017730 S.CER C1005 JB 1H 471K-T
C560 4030017730 S.CER C1005 JB 1H 471K-T
C561 4030017730 S.CER C1005 JB 1H 471K-T
C562 4030017730 S.CER C1005 JB 1H 471K-T
C563 4030016930 S.CER C1005 JB 1A 104K-T
C564 4030016930 S.CER C1005 JB 1A 104K-T
C565 4030016930 S.CER C1005 JB 1A 104K-T
C566 4030017460 S.CER C1005 JB 1H 102K-T
C567 4030016930 S.CER C1005 JB 1A 104K-T
C568 4030017460 S.CER C1005 JB 1H 102K-T
C569 4550006250 S.TAN TEESVA 1A 106M8R
Eqv. 4550007520 S.TAN F931A106MAABMA
C573 4030016930 S.CER C1005 JB 1A 104K-T
C574 4030016930 S.CER C1005 JB 1A 104K-T
C575 4510009020 S.ELE EEE0JA331P
J501 6510019121 S.CON S8B-PH-SM4-TB(LF)(SN)
J502 6510019121 S.CON S8B-PH-SM4-TB(LF)(SN)
J503 6450002210 CON 3017-8821
J504 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN)
DS500 5030004230 LCD L5-1077TRR
DS501 5040002710 LED EMPG3338S
DS502 5040002720 LED EMVR3338S
DS503 5040002710 LED EMPG3338S
DS504 5040002720 LED EMVR3338S
DS505 5040002310 S.LED SML-311YTT86
DS506 5040002310 S.LED SML-311YTT86
DS507 5040002310 S.LED SML-311YTT86
DS508 5040002310 S.LED SML-311YTT86
DS509 5040002310 S.LED SML-311YTT86
DS510 5040002310 S.LED SML-311YTT86
DS511 5040002150 LED VRPG3349S-734
DS512 5040002150 LED VRPG3349S-734
S506 2250000511 ENC RH70N1037E20-13F-2781
SP501 2510001910 SPE ND3050GA13Y04 <EVT>
MF1 2710001020 FAN MGT6012HR-O15
2710001020 FAN MGT6012HR-O15
MF2 2710001020 FAN MGT6012HR-O15
2710001020 FAN MGT6012HR-O15
W501 8900011801 CAB OPC-1199A
W502 8900017541 CAB OPC-1785-1
EP501 8930065150 LCD SRCN-2781-SP-N-W (SHJ)
EP503 6910019600 SPA LM-5
EP504 6910019610 SPA LM-7 (SPACER)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
(Amended page)
[CONNECT UNIT]
H/V REF
M.
LOCATION NO.
B 29.7/60.9 C601
C602
B 168.1/28.2 C603
B 137.4/32.4 C604
B 134.3/32.5 C605
B 161.0/27.5 C606
B 44.2/47.5 C607
B 158.1/19.3 C608
B 140.7/17.6 C609
B 148.6/18.0 C610
B 143.2/23.6 C611
B 143.5/22.1 C612
C613
B 166.3/51.1 C614
B 153.1/51.2 C615
B 162.0/47.0 C616
B 147.4/46.7 C617
B 105.2/28.1 C618
B 103.2/28.0 C619
B 44.0/29.9 C620
B 42.9/49.5 C621
B 42.9/50.4
B 67.3/6.6
B 89.7/40.7 J601
J602
B 34.8/23.8
B 62.6/12.0
B 106.0/11.4 S1
B 26.9/27.6 W601
B 52.9/15.2
B 18.4/57.1
T 111.3/43.2
T 101.3/43.2
T 91.3/43.2
T 81.3/43.2
T 71.3/43.2
T 61.3/43.2
[#07]
[#09]
[#07]
[#09]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
2
PART
DESCRIPTION
NO.
4030017420 S.CER C1005 CH 1H 470J-T
4030017400 S.CER C1005 CH 1H 220J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017400 S.CER C1005 CH 1H 220J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
6510027920 S.CON IMSA-9631S-28Y934
6510023210 CON CD6125SA1J0
2260003070 S.SWI MINISMDC150F/24-2
8900017500 CAB OPC-1852 (P0.5N28L90)
H/V
M.
LOCATION
T 13.8/12.4
T 12.2/12.4
T 16.6/12.4
T 15.0/14.2
T 17.8/13.9
T 19.4/12.4
T 20.6/13.9
T 22.7/12.4
T 25.5/12.4
T 29.7/12.8
T 31.0/14.1
T 32.5/12.8
T 33.6/14.1
T 35.2/14.1
T 35.8/12.8
B 35.2/15.6
T 37.6/13.6
T 39.3/12.2
T 39.9/13.4
T 41.3/12.6
T 27.4/13.9
B 22.8/16.2
B 38.9/18.0
